Electronic Control Gear
>
HID>
IgnitorsHID ignitors for series systems
Digital ignitors for maximum reliability
HID ignitors for series systems
Product Benefits
•Easy installation and wiring
•Can operate with both semi-parallel and
series ballasts
•Digital ignitors ensure maximum reliability
Product Features
•Ignitors equipped with screw terminal blocks
as standard
•Series ignitor will only work in series circuits
Applications
•Outdoor lighting (most popular application:
road and tunnel lighting)
System
•Electromagnetic system requires ballast,
ignitor and capacitor
•Designed to work only in series circuits
•No ignitor needed for SON-I lamps
A1
B1
C1
D1
A2
Dim. A1 A2 B1 C1 D1
no.
nom. nom. nom. nom. nom.
1 84.5 65 41.0 38.0 4.3
2 84.5 65 41.5 38.5 4.3
3 85.5
41.5 38.5
A1
B1
C1
D1
M8
A2
Dim. A1 A2 B1 C1 D1
no.
nom. nom. nom. nom. nom.
4 89 70 41.0 38.0 4.3
5 89 70 41.5 38.5 4.3
A1
A2
B1
C1
D1
Dim. A1 A2 B1 C1 D1
no.
nom. nom. nom. nom. nom.
6 114.5 95 41 38 4.3
A3
M8x10
Dim. A1 A3 B1 C1
no.
nom. nom. nom. nom.
7 78 62 36 32
Type
Rated Ballast-Lamp Power/Rated
Lamptype
Line Voltage Line Frequency Dim. no. Packing type/
Packing
configuration
National
Order Code
Ordering
number
8711500...
(V)
(Hz)
SI 51
250/400 HPI
220-240
50/60
1
UNP / 48 48
SI51
915535
30
SI 51-S
1,000 HPI
220-240
50/60
4
UNP / 20 20
SI51S
747495
30
SI 52
250/400 HPI
220-240
50/60
1
UNP / 48 48
SI52
915542
30
SI 54
2,000 HPI
380-415
50/60
6
1NO / 20 20
SI54
915481
30
SN 57
50/70 SON
220-240
50/60
1
UNP / 48 48
SN57
915559
30
SN 57-S
50/70 SON
220-240
50/60
4
UNP / 20 20
SN57S
060525
30
SN 58
35-400 SON/CDM/MH/HPI
220-240
50/60
1
UNP / 48 48
SN58
915566
30
SN 58-S
50/70 SON-T
220-240
50/60
4
UNP / 20 20
SN58S
741752
30
SN 59
1000/1,800 SON/MHN
220-240
50/60
6
UNP / 20 20
SN59
915573
30
SN 61
1000/1,800 SON/MH
220-240
50/60
6
UNP / 20 20
SN61
916396
30
SND 57
50/70 SON
220-240
50/60
2
UNP / 48 48
SND57
930668
30
SND 58
35-600 SON/CDM/MH/HPI/HPA
220-240
50/60
2
UNP / 48 48
SND58
930682
30
SND 58-S
35-600 SON/CDM/MH/HPI/HPA
220-240
50/60
5
UNP / 20 20
SND58S
930705
30
SUD 10-S
50/70 SON/CDO
220-240
50/60
7
UNP / 30 30
SUD10S
931443
30
SX 26
26/35 SOX/SOX-E
220-240
50/60
6
UNP / 20 20
SX26
915900
30
SX 70
90 SOX/SOX-E
220-240
50/60
6
UNP / 20 20
SX70
915498
30
SX 72
35/55 SOX/SOX-E
220-240
50/60
6
UNP / 20 20
SX72
915610
30
SX 73
180 SOX
220-240
50/60
3
UNP / 48 48
SX73
920058
30
SX 74
91/135 SOX/SOX-E
220-240
50/60
6
UNP / 20 20
SX74
915696
30
SX 76
66/90 SOX
220-240
50/60
6
UNP / 20 20
SX76
916402
30
