AspiraVision DALI for CDM Elite Light Boost
AspiraVision DALI Compact (70 W) for CDM
Elite Light Boost - The electronic gear with
brains
Excellence enhanced by innovation –
AspiraVision HID electronic gear with DALI
interface for dimming and boosting of CDM
Elite Light Boost lamps
Product Benefits
•Dim and boost Elite Light Boost lamps for
energy saving and attraction lighting
•SOFTSTART allows installation with fewer
circuit breakers
•Loop Through allows faster, cost-e cient
installation
Product Feature
•DALI interface
•SOFT START feature
•Loop Through feature
•Improved thermal performance
•Voltage Drop Detection
Applications
•70 W: accent and decorative lighting for
shops, public spaces, lobbies and o ces
•Suitable for indoor use only
B2 B1
D1
A2
A1
C1
A1 A2 B1 B2 C1 D1
nom. nom. nom. nom. nom. nom.
188 170 82.7 63.7 34.5 4.8
Type Line Voltage Line Frequency Max ballast on
MCB(16A type
B)
Lifetime 90%
surv. @Tcaselife
Packing type/
Packing
configuration
National Order
Code
Ordering
number
8727900...
(V) (Hz) (x) (h)
HID-AV C DALI 70 /I CDM 220-240 50/60 32 40,000 1NO / 12 12 HIDAVCDALI70 94400600
AspiraVision Compact for CDM
AspiraVision Compact (35, 50 & 70 W) for
CDM – The smart electronic gear
AspiraVision is the mark of excellence in
HID electronic gear technology – high-end,
compact, lightweight and easy to use, with
added features for optimal performance of
35, 50 and 70 W CDM lamps.
The recently added switching function
provides maximum flexibility for users by
integrating three di erent wattage choices
into a single driver.
Product Benefits
•SOFT START allows installation with fewer
circuit breakers; Loop Through allows faster,
cost-e cient installation
•Longer lifetime
•Driver can be set to 35, 50 or 70 W with the
integrated switch, which means there is no
need to replace the driver if the installation
requires lower or higher-wattage lamps in
the future
Product Features
•SOFT START
•Loop Through (in independent version)
•Improved thermal performance
•Low electromagnetic interference
•Voltage drop detection
Applications
•Accent and decorative lighting for shops,
public spaces, lobbies and o ces
•Suitable for indoor use only
A1
A2
C1
B2 B1
D1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
1 110 98.5 75 63.5 32.1 4.5
B2 B1
D1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
2 189.2 170.7 83.5 34.7 4.8
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
3 162.2 143 82.9 32.4 4.8
