PrimaVision Twin for CDM
PrimaVision Twin (35 W & 70 W) for CDM -
The cost-e ective solution
Dual CDM lamp operation, single HID
electronic gear – improves cost e ectiveness
and increases luminaire design flexibility
Product Benefits
•Cost-e ective, plus design flexibility
•Optimal lamp performance thanks to
minimal lamp power tolerance
•Lamp life increased by up to 30% for CDM
lamps
Product features
•Single gear for two lamps
•Loop Through feature (in independent
version)
•Minimal lamp power spread
•Low gear energy losses
•Lamp end-of-life detection
•High Tambient and Tcase temperatures
•Long lifetime of 40,000 hours
Applications
•35 and 70 W: accent and decorative lighting
for shops, public spaces, lobbies and o ces
•Suitable for indoor use only
B1
D1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
1 245 226 94 35 4.5
D1
A1
A2
A3
B2
C1
B1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
2 135 123.5 75 63.5 32 4.5
C1
A1
A2 D1
B1 B2
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
3 165 153 90 80 32 4.5
B1
D1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
4 245 226 94 35 4.5
Type Line
Voltage
Line
Frequency
Max ballast
on MCB(16A
type B)
Dim. no. Packing type/
Packing
configuration
National Order
Code
Ordering
number
8727900...
(V) (Hz) (x)
HID-PV C 2x35 /I CDM SOFT START 220-240 50/60 20 1 UNP / 6 6 PVC2X35ICDM 89704300
HID-PV C 2x35 /S Int. Earth Loop CDM 220-240 50/60 14 2 UNP / 12 12 PVC2X35SCDM 89572800
HID-PV C 2x70 /S CDM 220-240 50/60 10 3 UNP / 12 12 HIDPVC270S 84579200
HID-PV C 2x70 /I CDM SOFT START 220-240 50/60 10 4 UNP / 6 6 HIDPVC270I 84580800
PrimaVision Power for CDM
PrimaVision Power (100 W & 150 W) for
CDM - High power packed in a small size
PrimaVision Power gear is designed for
optimal performance of 100 and 150 W CDM
lamps – ideal where high-intensity light is key.
Product Benefits
•Optimal lamp performance thanks to
minimal lamp power tolerance
•Lamp life increased by up to 30% for CDM
lamps
•Eliminates all visible lamp flicker
Product features
•Loop Through feature (in independent
version)
•Low gear energy losses
•Lamp end-of-life detection
•High Tambient and Tcase temperatures
•Long lifetime of 40,000 hours
Applications
•100 and 150 W: high-bay area, accent and
decorative lighting for shops, public spaces,
lobbies and o ces
•Suitable for indoor use only
B1 B2
D1
A2
A1
C1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
1 223.9 206 82.7 38.6 34.2 4.8
D1
A1
A2
B2
C1
B1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
2 135 123.5 75 63.5 32 4.5
D1
B1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
3 223.9 206 82.7 34.2 4.8
D1
A1
A2
A3
B2
C1
B1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
4 135 123.5 75 63.5 32 4.8
