Lamps & Lighting Electronics Catalogue 2014

170 / 272

> >
A2
A1
B1
C1
D1
A1 A2 B1 C1 D1
nom. nom. nom. nom. nom.
280 265 40 28 4.2
Type Line Voltage Line Frequency Lifetime 90% surv.
@Tcaselife
Packing type/
Packing
configuration
National Order
Code
Ordering number
8711500...
(V) (Hz) (h)
EXC 35 EII SOX 220-240 50/60 50,000 UNP / 25 25 EXC035S50 062383 30
EXC 36 EII SOX-E 220-240 50/60 50,000 UNP / 25 25 EXC036S50 062406 30
EXC 55 EII SOX 220-240 50/60 50,000 UNP / 25 25 EXC055S50 062420 30
DynaVision Programmable Xtreme for CDO
Xtreme drivers for maximum energy savings
Highly reliable and flexible electronic drivers
for CDO lamps; designed to save on energy
costs via integrated controls and to reduce
maintenance costs thanks to 80,000 hour
lifetime and integrated lightning protection.
The DynaVision Programmable product
family is the perfect basis for any sort of
lighting management solution.
Product Benefits
•Enables 2-way communication with the
lighting network (via DALI)
•Up to 40% energy saving due to the
integrated dimming options and very high
driver e ciency
•Minimises maintenance cost due to the
Xtreme lifetime of 80,000 hours and
integrated lightning protection
Product Features
•Programmable by means of standard digital
interface (DALI) and controllable via DALI
protocol
•Integrates several control options (Dyn-
aDimmer, LineSwitch, AmpDim, Constant
Light Output, Adjustable Light Output)
•Longest lifetime for electronic drivers:
80,000 hours with minimum 90% survival at
Tc = 80 °C
•Lightning protection 10 kV/5 kA
•Accurate lamp power stabilisation of 95-97%
over wide mains-voltage range of 180-300 V
Application
•Road lighting
•Residential lighting
•City beautification
A1
B2 B1
C1
D1
A2
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
1 150 133.6 90 70 40 4.5
D1
A2
B1 B2
A1
C1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
2 169 156 100 81.5 58 4.8
Type Line Voltage Line
Frequency
Lifetime 90%
surv.
@Tcaselife
Dim. no. Packing
type/Packing
configu-
ration
National Order Code Ordering
number
8718291...
(V) (Hz) (h)
HID-DV PROG Xt 50 Q CDO 208-277 50/60 80,000 1 1NO / 12 12 DVPROGXT50CDOQ 669166 00
HID-DV PROG Xt 70 Q CDO 208-277 50/60 80,000 1 1NO / 12 12 DVPROGXT70CDOQ 669180 00
HID-DV PROG Xt 100 Q CDO 208-277 50/60 80,000 1 1NO / 12 12 DVPROGXT100CDOQ 669203 00
HID-DV PROG Xt 150 Q CDO 208-277 50/60 80,000 1 1NO / 12 12 DVPROGXT150CDOQ 669227 00
HID-DV PROG Xt 250 C2 CDO 208-277 50/60 80,000 2 1NO / 6 6 DVPROGXT250CDO 222613 00
Philips Lamps and Lighting Electronic Catalogue 2014 170
