Lamps & Lighting Electronics Catalogue 2014

165 / 272

> >
Type Line
Voltage
Line
Frequency
Max ballast
on MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering number
(V) (Hz) (x) (h)
HID-PV C 100 /I CDM 220-240 50/60 17 40,000 1 UNP / 10 10 PVC100ICDM 8727900899511 00
HID-PV C 100 /S CDM 220-240 50/60 17 40,000 2 UNP / 12 12 PVC100SCDM 8727900897623 00
HID-PV C 150 /I CDM 220-240 50/60 6 3 UNP / 10 10 HIDPVC150I 8711500912879 30
HID-PV C 150 /S CDM 220-240 50/60 6 4 UNP / 12 12 HIDPVC150S 8711500910523 30
PrimaVision for SDW-TG
PrimaVision SDW-TG (50 W & 100 W)
for SDW-TG - High quality and robust
performance
Robust, lightweight and one-piece HID
electronic gear for SDW-TG lamps (mini
White SON)
Lightweight, one-piece electronic gear for
50 and 100 W SDW-TG lamps (mini White
SON)
Product Benefits
•Optimal lamp performance thanks to
minimal lamp power tolerance
•Reduces colour di erences between lamps
and initial lumen spread
•Performance is independent of mains voltage
Product features
•Available as Standard (/S) version for use in
a luminaire, or with separate strain relief for
independent use on a (false) ceiling
•Minimal lamp power spread
•Lamp end-of-life detection
•High Tambient and Tcase temperatures
•Long lifetime of 40,000 hours
Applications
•Shop lighting, for a cozy atmosphere (e.
g. in furniture shops) and excellent display
of fresh goods (e. g. in butcher’s shops,
bakeries, florists)
•Suitable for indoor use only
A3
A1
B1
C1
C3
Dim. A1 A3 B1 C1 C3
no. nom. nom. nom. nom. nom.
1 40 40 62 30 16
D1
A2
B1 B2
A3
A1
C1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
2 150 133.6 90 70 37 4.5
Type Line Voltage Line Frequency Max ballast on
MCB(16A type
B)
Dim. no. Packing type/
Packing
configuration
National Order
Code
Ordering number
(V) (Hz) (x)
HID Strain Relief RELIEF 1 1NO / 10 10 HIDPVCOVER 871150053986130
HID-PV 50 /S SDW-TG 220-240 50/60 24 2 UNP 10 PV50SSDWTG 872790088753200
HID-PV 100 /S SDW-TG 220-240 50/60 14 2 UNP 10 PV100SSDWTG 872790088754900
Philips Lamps and Lighting Electronic Catalogue 2014 165
