HF-Regulator Intelligent Touch DALI for PL-T/C and TL5C
A1
A2
B2 B1
C1
D1
A1 A2 B1 B2 C1 D1
nom. nom. nom. nom. nom. nom.
123 111 79 67 33 4.5
Dimming – a next step in energy saving.
Intelligent high-frequency electronic dimming
ballast, using DALI (Digital Addressable
Lighting Interface according to IEC 62386)
or Touch and Dim push-button protocol
for fluorescent lamps. Features Corridor
Mode, programmable with Philips MultiOne.
High-frequency operation improves light
quality and lamp lifetime. Pre-empts upcoming
legislation as it meets A1BAT requirements.
Product Benefits
•Programmed start: flicker-free ignition in
0.5 seconds and striation-free operation, no
stroboscopic e ects. Preheating the lamp
electrodes enables the lamps to be switched
on and o without reducing life
•Smart power ensures constant light, inde-
pendent of mains fluctuations, and dimming
from 3 to 100%
•Protected against excessive mains voltages,
incorrect connections and incorrect lamp
use
Product Features
•Extremely low stand-by losses, controlled
cut-o for dimming levels above 80%
•Combined with controls, additional energy
savings can be achieved
•Stop circuit is activated within 5 seconds of
lamp failure (safety stop), and ballast resets
automatically after lamp replacement
•HF operation improves light quality and lamp
lifetime
•Programmable Corridor Mode
•Compliant with European and Asian norms
and suitable for emergency lighting systems
Application
•Indoor general and task lighting applications
in combination with lighting control systems
(personal control, daylight linking and/or
movement detection)
Type Line
Voltage
Line
Frequency
Max ballast
on
MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(V) (Hz) (x) (h)
HF-Ri TD 2x 26-42 PL-T/C E+ 195-240 50/60 12 50,000 A1 BAT 1NO / 12 12 HFRTD22642PLTCE 241690 00
