HF-Regulator II for PL-T/C
Product Description:
•Compact, lightweight High-Frequency
electronic regulating ballast for PL-T and
PL-C compact fluorescent lamps
Product Benefits
•The lamp power can be dimmed from 1
to 100% via the Analog control input (in
accordance with the 1-10 V industry standard)
•Compliant with European and Asian norms
and suitable for emergency lighting systems
•HF operation improves light quality, lamp
lifetime
•Combined with controls, additional energy
savings can be achieved
Product Features
•Programmed start: flicker-free ignition < 0.5
seconds and striation-free operation, no
stroboscopic e ects. Preheating the lamp
electrodes enables the lamps to be switched
on and o without reducing life
•Smart power ensures constant light,
independent of mains fluctuations
•Up to 60% reduction in energy consumption
by using automatic lighting control systems
•Stop circuit is activated within 5 seconds
in the event of lamp failure (safety stop),
and ballast resets automatically after lamp
replacement
Applications:
•1-10 V installations with daylight linking
and/or movement detection (energy saving)
•1-10 V installations with remote control
systems (comfort)
•Installations with emergency back-up
according to VDE 0108-100 / EN 60598-22
•Installations with daylight-linked and remote
control systems
•Installations with infrared remote control
systems
•Conference rooms
•Cinemas
•Department stores, shops, supermarkets
•O ce buildings: insurance companies, banks,
government ministries
•Hospitals
•Hotels
A1
A2
B2 B1
C1
D1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
1 123 111 79 67 33 4.5
A2
A1
B2
C1
D1
B1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
2 123 111 79 67 33 4.5
Type Line
Voltage
Line
Frequency
Max ballast
on
MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8727900...
(V) (Hz) (x) (h)
HF-R 1x 26-42 PL-T/C EII 220-240 50/60 28 50,000 A1 1 UNP / 12 12 HFR126-42PLCT 809718 00
HF-R 2x 26-42 PL-T/C EII 220-240 50/60 12 50,000 A1 2 UNP / 12 12 HFR226-42PLCT 809725 00
