HF-Performer III for TL5 lamps
B1
D1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
1 360 350 30 22 4.2
2 280 265 39 21 4.2
3 360 350 30 21 4.2
4 425 415 30 21 4.2
An energy-e cient solution
HF-Performer III TL5 is a sustainable, slim
and high-frequency electronic ballast for TL5
and TL5 Eco fluorescent lamps. It is ideal for
applications where high energy e ciency is
required. The HF-Performer III range has a
robust design, meets all relevant international
safety and performance standards and is
energy-e cient (CELMA EEI A2 BAT).
Product Benefits
•Optimal savings can be achieved using
HF-PIII together with TL5 ECO lamps
(system solution).
•The programmed start enables the lamp to
be switched on and o without reducing
useful lamp life.
•DC emergency operation in line with
IEC/EN 60598-22 luminaire norms
•Suitable for luminaires in protection class I
and, after testing, class II
Product Features
•50,000-hour lifetime at maximum case
temperature, combined with over 60,000
on/o switches on one lamp
•Programmed, flicker-free, pre-heated
start (< 1.0 s) which allows the lamp to be
switched on and o without reducing useful
lamp life
•Active power factor correction to ensure
constant light, irrespective of mains-voltage
fluctuations
•The unit is protected against excessive mains
voltage and incorrect connections
•The universal connector Wago 251 o ers the
flexibility for horizontal-manual or push-in
robot wiring or vertical ALF-robot wiring.
Applications
•Used with movement-detection control
systems like Philips OccuPlus
•Indoor applications, such as o ce buildings,
hospitals, supermarkets, department stores,
industrial premises and schools
•Class I outdoor applications, e. g. industrial
premises and parking lot
Type Line
Voltage
Line
Frequency
Max
ballast on
MCB(16A
type B)
Lifetime
90% surv.
@Tcaselife
Energy
E ciency
Index
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering number
(V) (Hz) (x) (h)
HF-P 1x 14-35 TL5 HE III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP11435T5HEIII 8727900 90504500
HF-P 2x 14-35 TL5 HE III 220-240 50/60 28 53,000 A2 BAT 1 1NO / 12 12 HFP21435T5HEIII 8727900 90503800
HF-P 3/4x 14 TL5 III 220-240 50/60 28 100,000 A2 BAT 2 1NO / 10 10 HFP3414TL5EIII 8718291 72125300
HF-P 1x 24/39 TL5 HO III 220-240 50/60 28 50,000 A2 BAT 3 1NO / 12 12 HFP124TL5HOLLL 8727900 95224700
HF-P 2x 24/39 TL5 HO III 220-240 50/60 20 50,000 A2 BAT 3 1NO / 12 12 HFP224-39TLEIIL 8727900 95226100
HF-P 1x 49 TL5 HO III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP149TL5HOIII 8727900 86319200
HF-P 2x 49 TL5 HO III 220-240 50/60 12 50,000 A2 BAT 1 1NO / 12 12 HFP249TL5HOIII 8727900 86347500
HF-P 1x 54/55 TL5 HO/PL-L III 220-240 50/60 28 50,000 A2 BAT 1 UNP / 12 12 HFP154TL5HOIII 8727900 86348200
HF-P 2x 54/55 TL5 HO/PL-L III 220-240 50/60 12 50,000 A2 BAT 1 UNP / 12 12 HFP254TL5HOIII 8727900 86351200
HF-P 1x 80 TL5/PL-L III 220-240 50/60 15 50,000 A2 BAT 3 1NO / 12 12 HFP180TLPLLEIIL 8727900 95228500
HF-P 2x 80 TL5/PL-L III 220-240 50/60 12 50,000 A2 BAT 4 1NO / 12 12 HFP280T5PLLEIII 8727900 95230800
