Lamps & Lighting Electronics Catalogue 2014

196 / 272

> >
A2
B1
C1
A1
D1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
1 360 350 30 22 4.2
2 359 350 30 28 4.2
A2
D1
B1
C1
A1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
3 425 415 39 28 4.2
Type Line
Voltage
Line
Frequency
Max ballast
on
MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(V) (Hz) (x) (h)
HF-P 3/4x 14 TL5 EII 220-240 50/60 28 50,000 A2 1 UNP / 12 12 HFP3414TL5EII 059840 30
HF-P 1x 95-120 TL5 EII 220-240 50/60 12 50,000 A2 2 1NO / 12 12 HFP195120TL5VHO 914828 30
HF-P 2x 95-120 TL5 EII 220-240 50/60 6 50,000 A2 3 1NO / 10 10 HFP295120TL5VHO 914842 30
HF-Performer II for TL-D lamps
Product Description:
•Second-generation slim, lightweight HF
electronic ballasts for TL-D fluorescent
lamps, using Philips EII technology
Product benefits
•High CELMA Energy E ciency Index A2
•The programmed start enables the lamp to
be switched on and o more than 50,000
times without reducing useful lamp life
•Suitable for luminaires in protection class I
and, after testing, class II
Features
•Programmed start: flicker-free, warm start
circuit preheats (0.5 s) the lamp electrodes;
lamps can be switched on and o without
reducing useful life
•Smart power: constant light independent of
mains voltage fluctuations
•Unit is protected against excessive mains
voltages and incorrect connections
•Automatic stop circuit is activated within
5 seconds in case of lamp failure (safety
stop); ballast resets automatically after lamp
replacement
•Universal connector for both manual and
automatic wiring
Applications:
•Suitable for use with infrared remote control
systems (e. g. movement detection)
•Department stores, shops, supermarkets,
hotels, hospitals, o ce buildings, industrial
premises
•Airports, railway stations
•Outdoor lighting; in general suitable for
Class I applications
•Suitable for installations with emergency
back-up, according to VDE 0108 with
re-ignition< 0.5 s
A1
A2
B1
C1
D1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
1 280 265 30 28 4.2
A1
A2
B1
C1
D1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
2 280 265 30 28 4.2
Type Line
Voltage
Line
Frequency
Max ballast
on MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(V) (Hz) (x) (h)
HF-P 1x 70 TL-D EII 220-240 50/60 28 50,000 A2 1 UNP / 12 12 HFP170TLDEII 93411630
HF-P 2x 70 TL-D EII 220-240 50/60 12 50,000 A2 2 UNP / 12 12 HFP270TLDEII 05863830
Philips Lamps and Lighting Electronic Catalogue 2014 196
