HF-Performer II Xtreme for TL5/TL-D lamps
A1
A2
B1
C1
D1
A1 A2 B1 C1 D1
nom. nom. nom. nom. nom.
360 350 30 28 4.2
Xtreme drivers for long life and reliable
performance
HF-Performer Xtreme is a unique X-
technology from Philips that guarantees
the highest lifetime reliability for lamps and
enables an extra-long and reliable HF system
life with an energy e ciency index (CELMA
EEI) of A2.
Product Benefits
•HF-P XT has double the lifetime of standard
HF gear due to the special cooler “Xtreme”
long-life low-failure product design.
•Suitable for use in outdoor and industrial en-
vironments because the units are protected
against transients; also suitable for class I and
class II luminaires
•Extreme thermal robustness with average
lifetime of 50,000 hours at Tcase = 85 °C;
also extreme reliability and reduced failure
rate of 0.1%/1,000 hours
•HF-P Xtreme gear is optimized for the
unique dosing of the emitter, resulting in an
optimized lamp life
Product Features
•Protects against transient voltage peaks of
up to 4 kV and excessive mains voltage and
incorrect connections of up to 400 V
•Programmed, flicker-free, pre-heated
start (< 2.0 s) which allows the lamp to be
switched on and o without reducing useful
lamp life
•Active power factor correction to ensure
constant light, irrespective of mains-voltage
fluctuations
•Suitable for emergency lighting luminaires in
accordance with IEC/EN 60598-22
Application
•Ideal for applications with high maintenance
costs or where lamp failure is unacceptable
•Used with movement-detection control
systems like Philips OccuPlus
•Applications where gear replacement can
cause unsafe situations, hassle or high costs,
such as installations with high ceilings or
in geographically remote areas, tunnels,
airports or underground railway stations
•Industrial premises such as food processing
and petrochemical plants
Type Line
Voltage
Line
Frequency
Max ballast
on MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(V) (Hz) (x) (h)
HF-P Xt 2x 58 TL-D EII 220-240 50/60 12 100,000 A2 UNP / 12 12 HFPXT258TLDEII 912060 30
HF-Performer TL5 Circular
A1
A2
B2 B1
C1
D1
A1 A2 B1 B2 C1 D1
nom. nom. nom. nom. nom. nom.
103 93.5 67 57.5 30 4.5
Product Description
•Compact, square, lightweight, High Fre-
quency electronic ballasts for TL5 Circular
lamps
Benefits
•50% longer lamp life than with conventional
ballasts
•Up to 25% energy saving at constant
luminous flux compared with conventional
ballasts
•Constant light independent of mains voltage
fluctuations
Features
•Programmed start: flicker-free, warm-start
circuit
•Protected against excessive mains voltages
•Automatic stop circuit (safety stop) is
activated within 5 seconds in case of lamp
failure; ballast resets automatically after lamp
replacement
Applications
•Ideal for applications with high switching
frequency, for example:
-Use with infrared remote control systems
(e. g. movement detection)
-Department stores, shops, supermarkets,
hotels, hospitals, o ce buildings
-Airports
-Installations with emergency back-up
according to VDE 0108-100 / EN 60598-22
with re-ignition < 0.5 s
