HF-Performer III for TL-D lamps
B1
D1
A2
A1
C1
Dim. A1 A2 B1 C1 D1
no. nom. nom. nom. nom. nom.
1 280 265 30 28 4.2
2 280 265 40 28 4.2
An energy-e cient solution
HF-Performer III TLD is a sustainable, slim
and high-frequency electronic ballast for TL-D
fluorescent lamps. It is ideal for applications
where high energy e ciency is required. The
HF-Performer III range has a robust design,
meets all relevant international safety and
performance standards and is energy-e cient
(CELMA EEI A2).
Product Benefits
•The programmed start enables the lamp to
be switched on and o without reducing
useful lamp life.
•DC emergency operation in line with
IEC/EN 60598-22 luminaire norms
•Smart power ensures constant light,
irrespective of mains-voltage fluctuations
•Suitable for luminaires in protection class I
and, after testing, class II
•The universal connector Wago 251 o ers the
flexibility for horizontal-manual or push-in
robot wiring or vertical ALF-robot wiring.
Product Features
•50,000-hour lifetime at maximum case
temperature, combined with over 60,000
on/o switches on one lamp
•Programmed, flicker-free, pre-heated
start (< 1.0 s) which allows the lamp to be
switched on and o without reducing useful
lamp life
•Active power factor correction to ensure
constant light, irrespective of mains-voltage
fluctuations
•The unit is protected against excessive mains
voltage and incorrect connections.
Application
•Used with movement-detection control
systems like Philips OccuPlus
•Indoor applications, such as o ce buildings,
hospitals, supermarkets, department stores,
industrial premises and schools
•Class I outdoor applications, e. g. industrial
premises and parking lots
Type Line
Voltage
Line
Frequency
Max ballast
on
MCB(16A
type B)
Lifetime 90%
surv.
@Tcaselife
Energy
E ciency
Index
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8727900...
(V) (Hz) (x) (h)
HF-P 1x 18 TL-D III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP118TLDIII 91158900
HF-P 2x 18 TL-D III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP218TLDIII 91160200
HF-P 3/4x 18 TL-D III 220-240 50/60 28 50,000 A2 BAT 2 1NO / 10 10 HFP3418TLDIII 91162600
HF-P 1x 36 TL-D III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP136TLDIII 91164000
HF-P 2x 36 TL-D III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP236TLDIII 91166400
HF-P 1x 58 TL-D III 220-240 50/60 28 50,000 A2 BAT 1 1NO / 12 12 HFP158TLDIII 91170100
HF-P 2x 58 TL-D III 220-240 50/60 12 50,000 A2 BAT 1 1NO / 12 12 HFP258TLDIII 91172500
HF-Performer II (flat) for TL5 lamps
Product Description
•Second-generation flat, slim, lightweight
high-frequency electronic ballast for TL5
fluorescent lamps, based on EII technology
Product benefits
•High CELMA Energy E ciency Index A2
•Optimal savings can be achieved using HF-PII
together with TL5 ECO lamps (system
solution)
•The programmed start enables the lamp to
be switched on and o more than 50,000
times without reducing useful lamp life
Features
•Programmed start: flicker-free, warm
start circuit preheating (0.5 s) the lamp
electrodes; this enables the lamps to be
switched on and o without reducing useful
life
•Smart power: constant light independent of
mains voltage fluctuations
•Unit is protected against excessive mains
voltages and incorrect connections
•Automatic stop circuit is activated within 5
seconds in case of lamp failure (safety stop);
once the lamp has been replaced, the ballast
resets automatically
•Equipped with universal connector for both
manual and automatic wiring
Applications
•Department stores, shops, supermarkets
•Industrial premises
•Airports, railway stations
•Outdoor lighting
•O ce buildings, for example insurance
companies, banks, government ministries
•Hospitals
•Hotels
•Suitable for emergency installations
according to VDE 0108, re-ignition< 0.5 s
