Eaton Industrial Switchgear - xStart switching, protections and actuating motors

323 / 439

Connection system SmartWire
2010 CA08103002Z-EN
8/39
Accessory
SmartWire connection cable1)
Length: 85 mm SWIRE-CAB-008
107032
25 off Cable lengths: Engineering￫A8/40
Length: 110 mm SWIRE-CAB-011
107033
Length: 150 mm SWIRE-CAB-015
107034
5 off
Length: 250 mm SWIRE-CAB-025
107035
Length: 500 mm SWIRE-CAB-050
112027
1 off
Length: 1000 mm SWIRE-CAB-100
107036
Length: 2000 mm SWIRE-CAB-200
107037
Termination connector1)
– Termination plug for last SmartWire card,
6 pole, no electrical function.
SWIRE-CAB-000
107031
25 off –
Data cable1)
– 6-core, ribbon cable, length: 100 m. SWIRE-CAB-100M
107038
1 off Preassembly of cable only possible with
special tool.
Plug1)
– 6-pin plug for ribbon cable. SWIRE-CAB-CON
107039
50 off For use with SWIRE-CAB-100M.
NHI-E with cable 1)
– NHI-E-10-PKZ0 with connection cable AWG18 blue,
for connection to SmartWire module for DILM.
NHI-E-10L-PKZ0
107040
5 off –
Plug-in reversing bridge 2)
– For assembling reversing starters with tool-less
plug connection
DILM12-XR
110099
20 off For use with DILM7…DILM15, without A2 link.
Information relevant for export to North America
1)
Product Standards IEC/EN 60947-4-1; UL 508;
CSA-C22.2 No. 14-05; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 2252-01
NA Certification UL Listed, CSA certified
2)
Product Standards IEC/EN 60947-4-1; UL 508;
CSA-C22.2 No. 14-05; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 012528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Description Part no.
Article no.
Price
See price
list
Std. pack Notes
SWIRE-… HPL08039EN
