Connection system SmartWire
2010
CA08103002Z-EN
www.eaton.comLED indicators
Operational
Ready: green
Ready: green
Power supply, SmartWire contactors
–
U
Aux
:
green
MODBUS status
–
MODBUS: yellow
SmartWire status
–
SmartWire: green
Output status
Q1, Q2: green
–
Connection floating contacts
Number
4
–
Rated voltage (internal supply)
U
e
V DC 17
–
Input current at “1” signal, typically
mA
5
–
Potential isolation
–
Yes
Max. cable length
m
< 2.8
–
MODBUS
Terminal type
–
SUB-D, 9 pole, socket RS232/RS485
Station address
–
1 … 31
Address setting
–
DIP switches
Potential isolation
From U
AUX
power supply
–
Yes
From U
Gateway
power supply
–
Yes
To SmartWire
–
Yes
Function
–
MODBUS-RTU
Slave
Bus protocol
–
MODBUS-RTU
Bus Terminating Resistors
–
can be connected via plug
Baud rate
–
Adjustable up to 57.6 (9.6/19.2/38.4)
kbit/s
SmartWire
Terminal type
Plug, 6-pole
Plug, 6-pole
Data/power cable
6-
core ribbon cable
6-
core ribbon cable
Maximum cable length, SmartWire system
m
Max. 4
Max. 4
Bus termination
Plug connectors
No
Station address
1…16
Automatic assignment
Station
Max. 4 SmartWire modules per line.
Max. 16
Address setting
automatically via SmartWire
None
Potential isolation
From U
AUX
power supply
No
No
From U
Gateway
power supply
No
No
Function
SmartWire slave
SmartWire master
Data transfer time, SmartWire system
Write switch
Normally 20 ms for all stations
–
Read status information
Normally 10 ms per station
–
Relay outputs
Rated impulse withstand voltage
U
imp
V AC 4000
–
Overvoltage category/pollution degree
III/3
Rated insulation voltage
U
i
V
250
–
Rated operating voltage
U
e
V
250
–
Making capacity
A
30
–
Breaking capacity
380/400
V A
10
–
Rated operational current
AC-15, 250 V
I
e
A
3
–
DC-12, 30 V
I
e
A
3
–
Conventional thermal current
I
th
A
6
6
Short-circuit rating without welding
max. fuse
A gG/gL 10
–
SWIRE-4DI-2DO-R
SWIRE-GW-MB
SWIRE-…
