Connection system SmartWire
2010 CA08103002Z-EN
8/41
Technical data
SWIRE-GW-DP SWIRE-PF SWIRE-DIL
General
Standards
General IEC/EN 60947
EN 55011
EN 55022
IEC/EN 61000-4
IEC/EN 60068-2-27
Profibus-DP IEC 61158 – –
Mounting Top-hat rail IEC/EN 60715 (35mm) or screw fixing with fixing
brackets ZB4-101-GF1 (accessories)
on DILM7…DILM38
Dimensions (w x d x h) mm 35 x 90 x 109 35 x 90 x 74 45 x 44 x 81
Weight kg 0.15 0.1 0.04
Terminal capacity
Solid mm2 0.34…1.5 0.34…1.5 0.34…1.5
Flexible with ferrule mm2 0.34…1.5 0.34…1.5 0.34…1.5
Solid or stranded AWG 22…16 22…16 22…16
Flat-blade screwdriver mm 3.5 x 0.8 3.5 x 0.8 3.5 x 0.8
Max. tightening torque Nm 0.6 0.6 0.5
Ambient climatic conditions
Ambient temperature Operation °C -25 - +55 -25 - +55 -25 - +60
Storage °C -25 - +70 -25 - +70 -25 - +70
Condensation Prevent condensation by means of suitable measures
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 - 95 5 - 95 5 - 95
Air pressure (in operation) hPa 795 - 1080 795 - 1080 795 - 1080
Ambient mechanical conditions
Protection type (IEC/EN 60529) IP20 IP20 IP20
Pollution degree 2 2 2
Mounting position Vertical Vertical As per DILM7 to DILM38
Electromagnetic compatibility (EMC)
Electrostatic discharge (IEC EN 61000-4-2, Level 3, ESD)
Air discharge kV 8 8 8
Contact discharge kV – – –
Electromagnetic fields
(IEC/EN 61000-4-3, RFI)
V/m 10 10 10
Radio interference suppression (EN 55011, EN 55022) Class A Class A Class A
Burst pulses
(IEC/EN 61000-4-4, level 3)
Supply cables kV 2 2 2
Signal cables kV 2 2 2
High-energy pulses (surge)
(IEC/EN 61000-4-5, level 2)
kV 0.5 (supply cables, symmetrical)
Emitted RFI (IEC/EN 61000-4-6) V 10 10 10
Insulation resistance
Clearances and creepage distances EN 50178, EN 60947-1, UL 508, CSA C22.2 No 142
Insulation resistance EN 50178, EN 60947-1
Supply voltage, gateway electronics and SmartWire station electronics
Ugateway
Rated operational voltage Ugateway V DC 24, -15 %, +20 % – –
Permissible range 20.4...28.8 20.4...28.8 Supply from gateway or
power module
Ripple % ≦ 5 – –
Maximum coupling unit power consumption at
24 V DC
mA 500
(typically 100 for gateway +
typically 25 per SmartWire
module)
– –
Voltage dips (IEC/EN 61131-2) ms 10 – –
Heat dissipation at 24 V DC W Normally 6 Normally 1 Normally 0.6
Protection against polarity reversal Yes
Short-circuit protection, SmartWire side Yes – –
SWIRE-…
