8/40 Connection system SmartWire
2010 CA08103002Z-EN
Engineering
Cable lengths
For connection between motor starters and contactors DILM, the cable lengths depend on the combination and assembly of the devices.
Applications PKZ accessories from to Cable length
Contactors DILM None
(45 grid)
DILM7-…15 DILM7-…15 85 mm
DILM17-…38 DILM17-…38 85 mm
DILM7-…38 DILM17-…38 110 mm
DILM17-…38 DILM7-…15 110 mm
PKZM0 with U-/A…/NHI…/AGM… DILM7-…15 DILM7-…15 110 mm
DILM17-…32 DILM17-…32 110 mm
DILM7-…15 DILM17-…32 110 mm
DILM17-…32 DILM7-…15 110 mm
Motor starters MSC None
(45 grid)
DILM7-…15 DILM7-…15 85 mm
DILM17-…32 DILM17-…32 85 mm
DILM7-…15 DILM17-…32 110 mm
DILM17-…32 DILM7-…15 110 mm
PKZM0 with U-/A…/NHI…/AGM… DILM7-…15 DILM7-…15 110 mm
DILM17-…32 DILM17-…32 110 mm
DILM7-…15 DILM17-…32 150 mm
DILM17-…32 DILM7-…15 150 mm
The cable lengths for connecting SmartWire devices depend on the combination and assembly of the devices.
Applications Cable length
Connection from power module to SWIRE-DIL with mounting beside PKZ 250 mm
Connection from power module to SWIRE-DIL with mounting beside DILM 150 mm
Connection from gateway to SWIRE-DIL with mounting beside PKZ 250 mm
Connection from coupling unit to SWIRE-DIL with mounting beside DILM 250 mm
Magnet systems
The number of motor starters or contactors DILM that can be connected is dependant on the power consumption of the magnet systems per SmartWire line.
To increase the number of SmartWire modules that can be connected, power modules can be used.
24 V DC DILM7 DILM 9 DILM12 DILM15 DILM17 DILM25 DILM32/38
Pick-up power W 3 3 4.5 12at 24 V 12 at 24 V 12 at 24 V 12 at 24 V
Holding power W 3 3 4.5 0.5 at 24 V 0.5 at 24 V 0.5 at 24 V 0.5 at 24 V
SWIRE-…
