Motor-starter combinations
Function Blocks
2010 CA08103002Z-EN
for North America 8/35
forNorthAmericaFunctionBlocks
Rating data for approved types1) Max. rated motor
current
Contactor Overload relay Maximum short-circuit protective device for North
America
Maximum motor rating Fuse
CEC or NEC
Circuit-breaker2)
Alternating current HP Continuous
current
Short-circuit
release
200 V
208 V
230 V
240 V
460 V
480 V
575 V
600 V
Type Type
3)
HP HP HP HP A A A
Modules DIL, Z
– – ½ ½ 1 DILEM-…(…) ZE-1.0 3 15 –
– – ¾ 1 1.4 DILEM-…(…) ZE-1.6 6 15 –
½ ½ 1 1½ 2.3 DILEM-…(…) ZE-2.4 6 15 –
– 1 2 3 3.9 DILEM-…(…) ZE-4 15 15 –
1½ 1½ 3 – 6 DILEM-…(…) ZE-6 20 15 –
– 2 – – 6.8 DILEM-…(…) ZE-9 35 15 –
2 2 5 5 7.8 DILEM-…(…) ZE-9 35 15 –
2 3 5 5 9.6 DILEM-…(…) ZE-12 45 – –
– – ½ ½ 1 DILM7…(…) ZB12-1 3 25 200
– – ¾ 1 1.4 DILM7…(…) ZB12-1,6 6 25 200
½ ½ 1 1½ 2.3 DILM7…(…) ZB12-2,4 6 25 200
1 1 2 3 3.9 DILM7…(…) ZB12-4 15 25 200
1½ ½ 3 – 6 DILM7…(…) ZB12-6 20 25 200
– – – 7½ 9 DILM9…(…) ZB12-10 25 25 200
– 3 5 7½ 9.6 DILM12…(…) ZE-12 25 25 200
– – 7½ 10 11 DILM12…(…) ZB12-12 45 25 200
– 5 10 – 15.2 DILM15…(…) ZB12-16 60 40 320
– – ½ ½ 1 DILM17…(…) ZB32-1 3 25 200
– – ¾ 1 1.4 DILM17…(…) 278447 6 25 200
½ ½ 1 1½ 2.3 DILM17…(…) ZB32-2,4 6 25 200
1 1 2 3 3.9 DILM17…(…) ZB32-4 15 25 200
½ 1½ 3 – 6 DILM17…(…) ZB32-6 20 25 200
– 3 5 7½ 9.6 DILM17…(…) ZB32-10 25 25 200
– – 7½ 10 11 DILM17…(…) ZB32-16 40 30 320
– 5 10 – 15.2 DILM17…(…) ZB32-16 40 30 320
– 7½ 15 20 22 DILM25…(…) ZB32-24 90 100 1200
– 10 20 25 32.2 DILM32…(…) ZB32-32 125 125 1200
– 3 5 7½ 9.6 DILM40(…) ZB65-10 40 40 380
– 5 10 10 15.2 DILM40(…) ZB65-16 60 60 760
– 7½ 20 25 32.2 DILM40(…) ZB65-24 90 90 1200
– 10 20 30 34 DILM40(…) ZB65-40 125 125 1200
– 20 40 50 54 DILM50(…) ZB65-57 200 150 2000
– 20 50 50 63 DILM65(…) ZB65-65 200 160 2000
– 25 50 60 68 DILM80(…) ZB150-70 250 250 2500
– 30 75 100 99 DILM95(…) ZB150-100 400 400 3200
– 40 100 100 124 DILM115(…) ZB150-125 500 500 4000
– 60 125 125 156 DILM150(…) ZB150-150 600 600 4800
50 60 125 150 156 DILM185A/22(…) Z5-160/FF225A 600 CLASS J 600 7200
60 75 150 200 192 DILM225A/22(…) Z5-220/FF225A 800 CLASS J 800 16000
75 100 200 250 248 DILM250/22(…) Z5-250/FF250 700 CLASS J 600 –
100 125 250 300 312 DILM300A/22(…) ZW7-400 1000 1000 –
125 150 300 400 382 DILM400/22(…) ZW7-400 1000 1000 –
150 200 400 500 480 DILM500/22(…) ZW7-540 1000 600 –
Notes 1) Devices for world markets IEC ≙ UL/CSA
2) Circuit-breaker -> Chapter 17
3) The electronic overload relay ZEV can alternatively be used on request.
DILM, ZE, ZB, Z5, ZW7 HPL08035EN
