Motor-starter combinations
Reversing starters, modules
for North America
Basic unit Trip block Price
Total of
module prices
Euro
DG
Std.
pack
Notes
Type2) Type
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-0.6-PKZ2
033943
1 off
Terminal capacity of high-capacity compact starters PKZ2/ZM…/S
Main terminals
Cables Cu 75 °C, min. AWG 14, max. AWG 6
Torque 1.8 Nm
Control circuit terminals
Cables min. AWG 20, max. AWG 16 (0.5–1 mm2)
With insulated/uninsulated blade terminal, nominal size 2.8
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-1-PKZ2
033950
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-1.6-PKZ2
033952
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-2.4-PKZ2
033955
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-4-PKZ2
033957
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-6-PKZ2
033966
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-10-PKZ2
033967
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-16-PKZ2
033968
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-25-PKZ2
033969
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-32-PKZ2
033973
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZMR-40-PKZ2
033975
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-0.6-PKZ2
024232
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-1-PKZ2
028979
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-1.6-PKZ2
031352
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-2.4-PKZ2
033725
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-4-PKZ2
036098
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-6-PKZ2
038471
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-10-PKZ2
040844
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-16-PKZ2
043217
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-25-PKZ2
045590
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-32-PKZ2
047963
1 off
PKZ2-SP-FVR(*V*HZ)
925109
ZM-40-PKZ2
050336
1 off
For use
with networks with
grounded star point
Up to 27 A 600 Y/347 V AC
480 Y/277 V AC
27 – 42 A 480 Y/277 V AC
Service factor (SF) Set value Ir on the current scale, depending on the
load factor
SF = 1.15 ￫ Ir = 1 x In mot
SF = 1 ￫ Ir = 0.9 x I n mot
8/33
PKZ2-SP, ZMR, ZM HPL08033EN
