Motor-starter combinations
Reversing starters
Starters on busbar adapter
Motor starters
actuating voltage
24 V DC
Price
See price
list
Std.
pack
Motor
protective
circuit
breaker
Contactor Wiring set
Reversing
starters
Busbar
adapter
Mechanical con-
nection module,
electrical contact
module and
reversing connec-
tor
Notes
Part no.
Article no.
Type Type Type Type
MSC-R-0.25-M7(24VDC)/BBA
102997
1 off PKZM0-0,25 2 x DILM7-01(…) PKZM0-XRM12 BBA0R-25 The reversing starters (complete
devices) consist of a PKZM0 motor
protective circuit breaker and two
contactors DILM.
These combinations are mounted on bus-
bars.
The connection of the main circuit
between PKZ and contactor is estab-
lished with electrical contact modules.
Complete units with mechanical inter-
lock, starters up to 12 A also with
electrical interlock.
MSC-R-0.4-M7(24VDC)/BBA
102998
PKZM0-0,4 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-0.63-M7(24VDC)/BBA
102999
PKZM0-0,63 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-1-M7(24VDC)/BBA
103000
PKZM0-1 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-1.6-M7(24VDC)/BBA
103001
PKZM0-1,6 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-2.5-M7(24VDC)/BBA
103002
PKZM0-2,5 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-4-M7(24VDC)/BBA
103003
PKZM0-4 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-6.3-M7(24VDC)/BBA
103004
PKZM0-6,3 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-10-M7(24VDC)/BBA
103005
PKZM0-10 2 x DILM7-01(…) PKZM0-XRM12
MSC-R-10-M9(24VDC)/BBA
103006
PKZM0-10 2 x DILM9-01(…) PKZM0-XRM12
MSC-R-12-M12(24VDC)/BBA
103007
PKZM0-12 2 x DILM12-01(…) PKZM0-XRM12
MSC-R-10-M17(24VDC)/BBA
103008
PKZM0-10 2 x DILM17-01(…) PKZM0-XM32DE+
DILM32-XRL
BBA0R-32
MSC-R-12-M17(24VDC)/BBA
103009
PKZM0-12 2 x DILM17-01(…) PKZM0-XM32DE+
DILM32-XRL
MSC-R-16-M17(24VDC)/BBA
103010
PKZM0-16 2 x DILM17-01(…) PKZM0-XM32DE+
DILM32-XRL
MSC-R-25-M25(24VDC)/BBA
103011
PKZM0-25 2 x DILM25-01(…) PKZM0-XM32DE+
DILM32-XRL
MSC-R-32-M32(24VDC)/BBA
103012
PKZM0-32 2 x DILM32-01(…) PKZM0-XM32DE+
DILM32-XRL
Further information Page
Technical data PKZM0 ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
DILM accessories ￫5/54
8/29
MSC-R.../BBA HPL08029EN
