309 / 439
2010
CA08103002Z-EN
www.eaton.comMotor-starter combinations
Modules
Reversing starters
Circuit-breaker
Contactor
Contactor
Notes
Type “1” coordination
Type “2” coordination
Type
Type
Type
NZMN1-M32
2
x DILM40(…)
2
x DILM80(…)
The motor starter combinations consist of the motor protective
circuit-breaker and a contactor.
They comply with IEC/EN 60947-4-1 and VDE 0660 Part 102.
I
q
= conditional rated current.
NZMN1-M40
2
x DILM40(…)
2
x DILM80(…)
NZMN1-M50
2
x DILM50(…)
2
x DILM80(…)
NZMN1-M63
2
x DILM65(…)
2
x DILM80(…)
NZMN1-M80
2
x DILM80(…)
2
x DILM80(…)
NZMN1-M100
2
x DILM95(…)
2
x DILM95(…)
NZMN1-M100
2
x DILM115(…)
2
x DILM115(…)
NZMN2-M160
2
x DILM150(…)
2
x DILM150(…)
NZMN2-M200
2
x DILM185A/22(…)
2
x DILM185A/22(…)
NZMN2-M200
2
x DILM225A/22(…)
2
x DILM225A/22(…)
NZMN3-ME350
2
x DILM250/22(…)
2
x DILM250/22(…)
NZMN3-ME350
2
x DILM300A/22(…)
2
x DILM300A/22(…)
NZMN3-ME350
2
x DILM400/22(…)
2
x DILM400/22(…)
NZMN3-ME450
2
x DILM500/22(…)
2
x DILM500/22(…)
NZMN4-ME550
2
x DILM580/22(…)
2
x –
NZMN4-ME875
2
x DILM650/22(…)
2
x –
NZMN4-ME875
2
x DILM750/22(…)
2
x –
NZMN4-ME875
2
x DILM820/22(…)
2
x –
NZMN4-ME1400
2
x DILM1000/22(…)
2
x –
NZMH2-M50
2
x DILM80(…)
2
x DILM80(…)
The motor-starter combinations consist of the motor protective
circuit breaker or a circuit breaker and a contactor.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
I
q
= rated conditional short-circuit current.
NZMH2-M63
2
x DILM80(…)
2
x DILM80(…)
NZMH2-M80
2
x DILM80(…)
2
x DILM80(…)
NZMH2-M100
2
x DILM95(…)
2
x DILM95(…)
NZMH2-M125
2
x DILM115(…)
2
x DILM115(…)
NZMH2-M160
2
x DILM150(…)
2
x DILM150(…)
NZMH2-ME90
2
x DILM80(…)
2
x DILM80(…)
NZMH2-ME90
2
x DILM80(…)
2
x DILM80(…)
NZMH2-ME90
2
x DILM95(…)
2
x DILM95(…)
NZMH2-ME140
2
x DILM115(…)
2
x DILM115(…)
NZMH2-ME140
2
x DILM150(…)
2
x DILM150(…)
NZMH2-ME220
2
x DILM185A/22(…)
2
x DILM185A/22(…)
NZMH2-ME220
2
x DILM225A/22(…)
2
x DILM225A/22(…)
NZMH3-ME350
2
x DILM250/22(…)
2
x DILM250/22(…)
NZMH3-ME350
2
x DILM300A/22(…)
2
x DILM300A/22(…)
NZMH3-ME350
2
x DILM400/22(…)
2
x DILM400/22(…)
8/25
NZMN, NZMH, DILM
HPL08025EN
