Eaton Industrial Switchgear - xStart switching, protections and actuating motors

305 / 439

2010 CA08103002Z-EN
Motor-starter combinations
Complete units
Reversing starters
Motor starters
actuating voltage
24 V DC
Price
See price
list
Std. pack Motor protective
circuit breaker
Contactor Reversingstarter
wiring set
Notes
Part no.
Article no.
Mechanical
connection
module,
electrical
contact module
and reversing
connector
Type Type Type
MSC-R-0.25-M7(24VDC)
283190
1
off
PKZM0-0,25 DILM7-01(...) PKZM0-XRM12 The reversing starters (complete devices) consist of a
PKZM0 motor protective circuit breaker and two
contactors DILM.
With the adapterless top-hat rail mounting of starters
up to 12 A, only the motor-protective circuit-breaker on
the top-hat rail requires an adapter. The contactors are
provided with mechanical support via a mechanical
connection element.
Control wire guide with max. 6 conductors with up to
2.5 mm external diameter or 4 conductors up to 3.5 mm
external diameter.
From 16 A, the motor protective circuit breaker and
contactors are mounted on the top-hat rail adapter
plate.
The connection of the main circuit between PKZ and
contactor is established with electrical contact
modules.
Complete units with mechanical interlock, starters up
to 12 A also with electrical interlock.
When using auxiliary contacts DILA‐XHIT…
(→ 5/40) the electrical plugs can be pulled without
having to remove the front mounting auxiliary contact.
Cannot be combined with standard auxiliary contact
NHI-E-...-PKZ0-C with spring-loaded terminal.
MSC-R-0.4-M7(24VDC)
283191
PKZM0-0,4 DILM7-01(...) PKZM0-XRM12
MSC-R-0.63-M7(24VDC)
283192
PKZM0-0,63 DILM7-01(...) PKZM0-XRM12
MSC-R-1-M7(24VDC)
283194
PKZM0-1 DILM7-01(...) PKZM0-XRM12
MSC-R-1.6-M7(24VDC)
283195
PKZM0-1,6 DILM7-01(...) PKZM0-XRM12
MSC-R-2.5-M7(24VDC)
283197
PKZM0-2,5 DILM7-01(...) PKZM0-XRM12
MSC-R-4-M7(24VDC)
283198
PKZM0-4 DILM7-01(...) PKZM0-XRM12
MSC-R-6.3-M7(24VDC)
283200
PKZM0-6,3 DILM7-01(...) PKZM0-XRM12
MSC-R-10-M7(24VDC)
283201
PKZM0-10 DILM7-01(...) PKZM0-XRM12
MSC-R-10-M9(24VDC)
283202
PKZM0-10 DILM9-01(...) PKZM0-XRM12
MSC-R-12-M12(24VDC)
283203
PKZM0-12 DILM12-01(...) PKZM0-XRM12
MSC-R-10-M17(24VDC)
101051
PKZM0-10 DILM17-01(...) PKZM0-XRM32
MSC-R-12-M17(24VDC)
101052
PKZM0-12 DILM17-01(...) PKZM0-XRM32
MSC-R-16-M17(24VDC)
283204
PKZM0-16 DILM17-01(...) PKZM0-XRM32
MSC-R-25-M25(24VDC)
283205
PKZM0-25 DILM25-01(...) PKZM0-XRM32
MSC-R-32-M32(24VDC)
283206
PKZM0-32 DILM32-01(...) PKZM0-XRM32
Further information Page
Technical data PKZM0 ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
Further actuation voltages ￫5/73
DILM accessories ￫5/54
8/21
MSC-R: PKZM0, DILM HPL08021EN
