8/20 Motor-starter combinations
Complete units
Reversing starters
2010 CA08103002Z-EN
Reversing startersCompleteunits
Motor data Setting range Motor starters
actuating voltage
230 V 50 Hz
Price
See price
list
Rated
operational
power
Rated
operational
current
Rated short-circuit
current
Overload
trip
Short-
circuit
releases
Part no.
Article no.
AC-3 AC-3 380 - 415 V 380 - 415 V
380 V
400 V
415 V
400 V Type “1”
coordina-
tion
Type “2”
coordina-
tion
P Ie Iq Iq Ir Irm
kW A kA kA A A
Complete units MSC-R
0.06 0.21 150 50 0.16 - 0.25 3.5 MSC-R-0.25-M7(230V50HZ)
283171
0.09 0.31 150 50 0.25 - 0.4 5.6 MSC-R-0.4-M7(230V50HZ)
283172
0.12
0.18
0.41
0.6
150 50 0.4 - 0.63 8.82 MSC-R-0.63-M7(230V50HZ)
283173
0.25 0.8 150 50 0.63 - 1 14 MSC-R-1-M7(230V50HZ)
283175
0.37
0.55
1.1
1.5
150 50 1 - 1.6 22.4 MSC-R-1.6-M7(230V50HZ)
283176
0.75 1.9 150 50 1.6 - 2.5 35 MSC-R-2.5-M7(230V50HZ)
283178
1.1
1.5
2.6
3.6
150 50 2.5 - 4 56 MSC-R-4-M7(230V50HZ)
283179
2.2 5 150 50 4 - 6.3 88.2 MSC-R-6.3-M7(230V50HZ)
283181
3 6.6 150 – 6.3 - 10 140 MSC-R-10-M7(230V50HZ)
283182
4 8.5 150 – 6.3 - 10 140 MSC-R-10-M9(230V50HZ)
283183
5.5 11.3 50 – 8 - 12 168 MSC-R-12-M12(230V50HZ)
283184
3 6.6 50 50 6.3 - 10 140 MSC-R-10-M17(230V50HZ)
101049
4 11.3 50 50 8 - 12 168 MSC-R-12-M17(230V50HZ)
101050
7.5 15.2 50 50 10 - 16 224 MSC-R-16-M17(230V50HZ)
283186
11 21.7 50 50 20 - 25 350 MSC-R-25-M25(230V50HZ)
283187
15 29.3 50 50 25 - 32 448 MSC-R-32-M32(230V50HZ)
283188
I
M
3 ~
M
3 ~
MSC-R: PKZM0, DILM HPL08020EN
