Motor-starter combinations
Modules
DOL starters
Contactor Overload relay Contactor Overload relay Current sensor Notes
Type “1” coordination Type “1” coordination Type “2” coordination Type “2” coordination
Type Type Type Type Type
DILM7-…(…) ZB12-0,24 DILM7-…(…) ZB12-0,24 – The motor-starter combinations consist of the motor
protective circuit breaker (without overload function),
a contactor and overload relay modules.
They conform with IEC/EN 60947-4-1 or VDE 0660
Part 102.
Iq = conditional rated current
The combinations can be operated with or without
manual reset. In theManual position, the combination is
blocked against automatic restarting and must be reset
locally. In the Auto position, the combination automati-
cally switches on again after the bimetallic elements
have cooled down.
DILM7-…(…) ZB12-0,4 DILM7-…(…) ZB12-0,4 –
DILM7-…(…) ZB12-0,6 DILM7-…(…) ZB12-0,6 –
DILM7-…(…) ZB12-0,6 DILM7-…(…) ZB12-0,6 –
DILM7-…(…) ZB12-1 DILM7-…(…) ZB12-1 –
DILM7-…(…) ZB12-1,6 DILM7-…(…) ZB12-1,6 –
DILM7-…(…) ZB12-1,6 DILM7-…(…) ZB12-1,6 –
DILM7-…(…) ZB12-2,4 DILM7-…(…) ZB12-2,4 –
DILM7-…(…) ZB12-4 DILM7-…(…) ZB12-4 –
DILM7-…(…) ZB12-4 DILM7-…(…) ZB12-4 –
DILM7-…(…) ZB12-6 DILM17-…(…) ZB32-6 –
DILM9-…(…) ZB12-10 DILM17-…(…) ZB32-10 –
DILM9-…(…) ZB12-10 DILM17-…(…) ZB32-10 –
DILM12-…(…) ZB12-12 – – –
– – DILM17-…(…) ZB32-16 –
DILM17-…(…) ZB32-16 DILM17-…(…) ZB32-16 –
DILM25-…(…) ZB32-24 DILM25-…(…) ZB32-24 –
DILM32-…(…) ZB32-32 DILM32-…(…) ZB32-32 –
DILM40(…) ZB65-40 – – – The motor-starter combinations consist of the circuit-
breaker (without overload function), contactor and
overload relay module.
They conform with IEC/EN 60947-4-1 or VDE 0660
Part 102.
Iq = conditional rated current
The combinations can be operated with or without
manual reset. In theManual position, the combination is
blocked against automatic restarting and must be reset
locally. In the Auto position, the combination automati-
cally switches on again after the bimetallic elements
have cooled down.
Maximum tripping tolerance CLASS10.
– – DILM40(…) ZEV ZEV-XSW-65
DILM50(…) ZB65-57 – – –
– – DILM50(…) ZEV ZEV-XSW-65
DILM65(…) ZB65-57 – – –
– – DILM65(…) ZEV ZEV-XSW-65
DILM80(…) ZB150-70 – – –
– – DILM80(…) ZEV ZEV-XSW-145
DILM95(…) ZB150-100 – – –
– – DILM95(…) ZEV ZEV-XSW-145
DILM115(…) ZB150-100 – – –
– – DILM115(…) ZEV ZEV-XSW-145
Further information Page
Technical data PKZMO ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
Further actuating voltages ￫5/73
DIL accessories ￫5/56
Technical data ZB... ￫Chapter 6
Accessories ZB... ￫6/26
Further information Page
Technical data NZMN1 ￫Chapter 17
Accessories NZM1 ￫17/78
Technical data DILM ￫Chapter 5
Further actuating voltages ￫5/75
DIL accessories ￫5/54
Technical data ZB..., ZEV ￫Chapter 6
Accessories ZB... ￫6/26
Accessories ZEV ￫6/20
