Motor-starter combinations
Modules
DOL starters
Notes
Circuit-breaker Contactor Contactor
Type “1” coordination Type “2” coordination
Type Type Type
NZMN1-M40 DILM40(…) DILM80(…) The motor-starter combinations consist of the motor protective circuit breaker
or a circuit breaker and a contactor. They conform with IEC/EN 60947-4-1 or
VDE 0660 Part 102.
Iq = conditional rated current
NZMN1-M50 DILM50(…) DILM80(…)
NZMN1-M63 DILM65(…) DILM80(…)
NZMN1-M80 DILM80(…) DILM80(…)
NZMN1-M100 DILM95(…) DILM95(…)
NZMN1-M100 DILM115(…) DILM115(…)
NZMN2-M160 DILM150(…) DILM150(…)
NZMN2-M200 DILM185A/22(…) DILM185A/22(…)
NZMN2-M200 DILM225A/22(…) DILM225A/22(…)
NZMN3-ME350 DILM250/22(…) DILM250/22(…)
NZMN3-ME350 DILM300A/22(…) DILM300A/22(…)
NZMN3-ME350 DILM400/22(…) DILM400/22(…)
NZMN3-ME450 DILM500/22(…) DILM500/22(…)
NZMN4-ME550 DILM580/22(…) –
NZMN4-ME875 DILM650/22(…) –
NZMN4-ME875 DILM750/22(…) –
NZMN4-ME875 DILM820/22(…) –
NZMN4-ME1400 DILM1000/22(…) –
NZMH2-M50 DILM80(…) DILM80(…) The motor-starter combinations consist of the motor protective circuit breaker
or a circuit breaker and a contactor. They conform with IEC/EN 60947-4-1 or
VDE 0660 Part 102.
Iq = conditional rated current
NZMH2-M63 DILM80(…) DILM80(…)
NZMH2-M80 DILM80(…) DILM80(…)
NZMH2-M100 DILM95(…) DILM95(…)
NZMH2-M125 DILM115(…) DILM115(…)
NZMH2-M160 DILM150(…) DILM150(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME90 DILM95(…) DILM95(…)
NZMH2-ME140 DILM115(…) DILM115(…)
NZMH2-ME140 DILM150(…) DILM150(…)
NZMH2-ME220 DILM185A/22(…) DILM185A/22(…)
NZMH2-ME220 DILM225A/22(…) DILM225A/22(…)
NZMH3-ME350 DILM250/22(…) DILM250/22(…)
NZMH3-ME350 DILM300A/22(…) DILM300A/22(…)
NZMH3-ME350 DILM400/22(…) DILM400/22(…)
