Motor-starter combinations
Modules
DOL starters
Notes
Motor protective circuit
breaker
Contactor Contactor Current limiter
Type “1” coordination Type “2” coordination
Type Type Type Type
PKZM0-0,25 DILM7-…(…) DILM7-…(…) – The motor-starter combinations consist of the motor protective
circuit breaker or a circuit breaker and a contactor.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
Iq = rated conditional short-circuit current.
PKZM0-0,4 DILM7-…(…) DILM7-…(…) –
PKZM0-0,4 DILM7-…(…) DILM7-…(…) –
PKZM0-0,63 DILM7-…(…) DILM7-…(…) –
PKZM0-1 DILM7-…(…) DILM7-…(…) –
PKZM0-1 DILM7-…(…) DILM7-…(…) –
PKZM0-1,6 DILM7-…(…) DILM7-…(…) –
PKZM0-1,6 DILM7-…(…) DILM7-…(…) –
PKZM0-2,5 DILM7-…(…) DILM17-…(…) –
PKZM0-4 DILM7-…(…) DILM17-…(…) –
PKZM0-6,3 DILM7-…(…) DILM17-…(…) –
PKZM0-6,3 – DILM17-…(…) CL-PKZ0
PKZM0-6,3 DILM7-…(…) DILM17-…(…) –
PKZM0-6,3 – DILM17-…(…) CL-PKZ0
PKZM0-10 DILM9-…(…) DILM17-…(…) –
PKZM0-10 – DILM17-…(…) CL-PKZ0
PKZM0-10 DILM9-…(…) DILM17-…(…) –
PKZM0-10 – DILM17-…(…) CL-PKZ0
PKZM0-12 DILM12-…(…) DILM17-…(…) –
PKZM0-12 – DILM17-…(…) CL-PKZ0
PKZM0-16 DILM17-…(…) DILM17-…(…) –
PKZM0-16 – DILM17-…(…) CL-PKZ0
PKZM0-20 DILM25-…(…) – –
PKZM0-20 DILM25-…(…) – CL-PKZ0
PKZM0-25 DILM25-…(…) – –
PKZM0-25 DILM25-…(…) – CL-PKZ0
PKZM0-32 DILM32-…(…) – –
PKZM0-32 DILM32-…(…) – CL-PKZ0
PKZM4-25 DILM40(…) DILM40(…) – The motor-starter combinations consist of the motor protective
circuit breaker or a circuit breaker and a contactor.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
Iq = rated conditional short-circuit current.
PKZM4-25 DILM40(…) DILM40(…) –
PKZM4-32 DILM40(…) DILM40(…) –
PKZM4-40 DILM40(…) DILM40(…) –
PKZM4-50 DILM50(…) DILM50(…) –
PKZM4-58 DILM65(…) DILM65(…) –
PKZM4-63 DILM65(…) DILM65(…) –
Further information Page
Technical data PKZM... ￫Chapter 7
PKZM accessories... ￫7/10
Technical data DILM ￫Chapter 5
Further actuating voltages ￫5/73
DILM accessories ￫5/56
Further information Page
Technical data PKZM... ￫Chapter 7
PKZM accessories... ￫7/10
Technical data DILM ￫Chapter 5
Further actuating voltages ￫5/75
DILM accessories ￫5/56
8/13
PKZM, DILM HPL08013EN
