Motor-starter combinations
Compact starters, high-capacity compact starters
DOL starters
Part no.
Article no.
Price
See price list
Std. pack
Notes
PKZ2/ZM-1/SE1A/11(230V50HZ,240V60HZ
063364
1 off The compact starters consist of a motor protective circuit breaker,
which features a plug-in trip block and an attached contact module
with matching profile. The devices are prefitted to a clip plate and can
be snap fitted as a unit, centrally onto one or two IEC/EN 60715 top-hat
rails.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
Iq = rated conditional short-circuit current
PKZ2/ZM-1.6/SE1A/11(230V50HZ,240V60
063372
PKZ2/ZM-2.4/SE1A/11(230V50HZ,240V60
063382
PKZ2/ZM-4/SE1A/11(230V50HZ,240V60HZ
063392
PKZ2/ZM-6/SE1A/11(230V50HZ,240V60HZ
063402
PKZ2/ZM-10/SE1A/11(230V50HZ,240V60)
063412
PKZ2/ZM-16/SE1A/11(230V50HZ,240V60)
063422
PKZ2/ZM-25/SE1A/11(230V50HZ,240V60)
063432
PKZ2/ZM-32/SE1A/11(230V50HZ,240V60)
063442
PKZ2/ZM-40/SE1A/11(230V50HZ,240V60)
063452
PKZ2/ZM-1/S(230V50HZ,240V60HZ)
063472
1 off The high-capacity compact starters consist of a motor protective
circuit breaker and an attached contact module with matching profile.
The devices are prefitted to a clip plate and can be snap fitted as a unit,
centrally onto one or two IEC/EN 60715 top-hat rails.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
Iq = rated conditional short-circuit current
PKZ2/ZM-1.6/S(230V50HZ,240V60HZ)
063482
PKZ2/ZM-2.4/S(230V50HZ,240V60HZ)
063492
PKZ2/ZM-4/S(230V50HZ,240V60HZ)
063502
PKZ2/ZM-6/S(230V50HZ,240V60HZ)
063512
PKZ2/ZM-10/S(230V50HZ,240V60HZ)
063522
PKZ2/ZM-16/S(230V50HZ,240V60HZ)
063532
PKZ2/ZM-25/S(230V50HZ,240V60HZ)
063542
PKZ2/ZM-32/S(230V50HZ,240V60HZ)
063552
PKZ2/ZM-40/S(230V50HZ,240V60HZ)
063562
8/9
PKZ2/ZM.../S... HPL08009EN
