www.eaton.comMotor-starter combinations
Complete units 400/415 V
DOL starters
DOL startersCompleteunits 400/415V
Motor starters
actuating voltage
24
V DC
Std.
pack
Motor
protective
circuit breaker
Contactor
DOL starter
wiring set
Notes
Part no.
Article no.
Price
See price
list
Mechanical con-
nection module
and electrical
contact module
Type
Type
Type
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12 The DOL starters (complete devices) consist of a PKE
motor protective circuit breaker and a DILM
contactor.
With the adapterless top-hat rail mounting of starters
up to 15 A, only the motor protective circuit breaker on
the top-hat rail requires an adapter.
The contactors are provided with mechanical support
via a mechanical connection element.
Control wire guide with max. 6 conductors with up to
2.5
mm external diameter or 4 conductors up to 3.5 mm
external diameter.
From 16 A, the motor protective circuit breaker and
contactor are mounted on the top-hat rail adapter
plate.
The connection of the main circuit between PKE and
contactor is established with electrical contact
modules.
When using auxiliary contacts DILA‐XHIT…
(
→ 5/40) the electrical plugs can be pulled without
having to remove the front mounting auxiliary contact.
Cannot be combined with standard auxiliary contact
NHI-E-...-PKZ0-C with spring-loaded terminals.
The DOL starters MSC-DEA... are prepared for
communication via SmartWire-Darwin. For this the
SWD-PKE communication must be added.
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-1.2-M7(24VDC)
121753
1
off
PKE12/XTUA-1.2 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-4-M7(24VDC)
121754
1
off
PKE12/XTUA-4 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-4-M7(24VDC)
121754
1
off
PKE12/XTUA-4 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-4-M7(24VDC)
121754
1
off
PKE12/XTUA-4 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-4-M7(24VDC)
121754
1
off
PKE12/XTUA-4 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-12-M7(24VDC)
121755
1
off
PKE12/XTUA-12 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-12-M7(24VDC)
121755
1
off
PKE12/XTUA-12 DILM7-10(...)
PKZM0-XDM12
MSC-DEA-12-M9(24VDC)
121756
1
off
PKE12/XTUA-12 DILM9-10(...)
PKZM0-XDM12
MSC-DEA-12-M12(24VDC)
121757
1
off
PKE12/XTUA-12 DILM12-10(...) PKZM0-XDM12
MSC-DEA-12-M17(24VDC)
121758
1
off
PKE12/XTUA-12 DILM17-10(...) PKZM0-XDM32
MSC-DEA-12-M17(24VDC)
121758
1
off
PKE12/XTUA-12 DILM17-10(...) PKZM0-XDM32
MSC-DEA-12-M17(24VDC)
121758
1
off
PKE12/XTUA-12 DILM17-10(...) PKZM0-XDM32
MSC-DEA-12-M17(24VDC)
121758
1
off
PKE12/XTUA-12 DILM17-10(...) PKZM0-XDM32
MSC-DEA-32-M17(24VDC)
121759
1
off
PKE32/XTUA-32 DILM17-10(...) PKZM0-XDM32
MSC-DEA-32-M25(24VDC)
121760
1
off
PKE32/XTUA-32 DILM25-10(...) PKZM0-XDM32
MSC-DEA-32-M32(24VDC)
121761
1
off
PKE32/XTUA-32 DILM32-10(...) PKZM0-XDM32
Further information
Page
Technical data PKE
￫Chapter 7
Accessories PKE
￫7/10
Technical data DILM
￫Chapter 5
Further actuating voltages
￫5/73
DILM accessories
→ 5/54
8/7
MSC-DEA: PKE, DILM
