www.eaton.comMotor-starter combinations
Complete units
DOL starters
Motor starters
actuating voltage
24
V DC
Std.
pack
Motor
protective
circuit breaker
Contactor
DOL starter wiring
set
Notes
Part no.
Article no.
Price
See price
list
Mechanical con-
nection module
and electrical
contact module
Type
Type
Type
MSC-D-0.25-M7(24VDC)
1)
283154
1
off
PKZM0-0,25
DILM7-10(...)
PKZM0-XDM12
The DOL starters (complete devices) consist of a
motor protective circuit breaker PKZM0 and a
contactor DILM.
With the adapterless top-hat rail mounting of starters
up to 15 A, only the motor-protective circuit-breaker
on the top-hat rail requires an adapter. The
contactors are provided with mechanical support
via a mechanical connection element.
Control wire guide with max. 6 conductors with up to
2.5
mm external diameter or 4 conductors up to
3.5
mm external diameter.
From 16 A, the motor protective circuit breaker and
contactors are mounted on the top-hat rail adapter
plate.
The connection of the main circuit between PKZ and
contactor is established with electrical contact
modules.
When using auxiliary contacts DILA‐XHIT…
(
→ 5/40) the electrical plugs can be pulled without
having to remove the front mounting auxiliary
contact.
Cannot be combined with NHI-E-...-PKZ0-C standard
auxiliary contact with spring-loaded terminal.
1)
To assemble Type F starters that conform with
UL508, incoming terminals BK25/3-PKZ0-E and, if
necessary, three-phaseterminal blocksB3.../...-PKZ0
can be added to motor starter combinations. Type F
starter ￫Page 8/34
MSC-D-0.4-M7(24VDC)
1)
283155
1
off
PKZM0-0,4
DILM7-10(...)
PKZM0-XDM12
MSC-D-0.63-M7(24VDC)
1)
283156
1
off
PKZM0-0,63
DILM7-10(...)
PKZM0-XDM12
MSC-D-1-M7(24VDC)
1)
283158
1
off
PKZM0-1
DILM7-10(...)
PKZM0-XDM12
MSC-D-1.6-M7(24VDC)
1)
283159
1
off
PKZM0-1,6
DILM7-10(...)
PKZM0-XDM12
MSC-D-2.5-M7(24VDC)
1)
283161
1
off
PKZM0-2,5
DILM7-10(...)
PKZM0-XDM12
MSC-D-4-M7(24VDC)
1)
283162
1
off
PKZM0-4
DILM7-10(...)
PKZM0-XDM12
MSC-D-6.3-M7(24VDC)
1)
283164
1
off
PKZM0-6,3
DILM7-10(...)
PKZM0-XDM12
MSC-D-10-M7(24VDC)
283165
1
off
PKZM0-10
DILM7-10(...)
PKZM0-XDM12
MSC-D-10-M9(24VDC)
283166
1
off
PKZM0-10
DILM9-10(...)
PKZM0-XDM12
MSC-D-12-M12(24VDC)
283167
1
off
PKZM0-12
DILM12-10(...)
PKZM0-XDM12
MSC-D-16-M15(24VDC)
100415
1
off
PKZM0-16
DILM15-10(...)
PKZM0-XDM12
MSC-D-10-M17(24VDC)
101047
1
off
PKZM0-10
DILM17-10(...)
PKZM0-XDM32
MSC-D-12-M17(24VDC)
101048
1
off
PKZM0-12
DILM17-10(...)
PKZM0-XDM32
MSC-D-16-M17(24VDC)
283168
1
off
PKZM0-16
DILM17-10(...)
PKZM0-XDM32
MSC-D-25-M25(24VDC)
283169
1
off
PKZM0-25
DILM25-10(...)
PKZM0-XDM32
MSC-D-32-M32(24VDC)
283170
1
off
PKZM0-32
DILM32-10(...)
PKZM0-XDM32
Further information
Page
Technical data PKZM0
￫Chapter 7
Accessories PKZ
￫7/10
Technical data DILM
￫Chapter 5
Further actuating voltages
￫5/73
DILM accessories
￫5/54
8/3
MSC-D: PKZM0, DILM
