Motor-starter combinations
Modules
DOL starters
Notes
Circuit-breaker Contactor Contactor
Type “1” coordination Type “2” coordination
Type Type Type
NZMH2-M20 DILM40(…) DILM80(…) The motor-starter combinations consist of the motor protective circuit breaker or
a circuit breaker and a contactor. They conform with IEC/EN 60947-4-1 or
VDE 0660 Part 102.
Iq = conditional rated current
NZMH2-M25 DILM40(…) DILM80(…)
NZMH2-M32 DILM40(…) DILM80(…)
NZMH2-M40 DILM40(…) DILM80(…)
NZMH2-M50 DILM80(…) DILM80(…)
NZMH2-M63 DILM80(…) DILM80(…)
NZMH2-M80 DILM80(…) DILM80(…)
NZMH2-M80 DILM80(…) DILM80(…)
NZMH2-M125 DILM115(…) DILM115(…)
NZMH2-M160 DILM150(…) DILM150(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME90 DILM80(…) DILM80(…)
NZMH2-ME140 DILM115(…) DILM115(…)
NZMH2-ME140 DILM150(…) DILM150(…)
8/17
NZMH, DILM HPL08017EN
