Motor-starter combinations
Modules
Reversing starters
Motor protective
circuit breaker
Contactor Contactor Notes
Type “1”
coordination
Type “2”
coordination
Type Type Type
PKZM0-0,25 2 x DILM7-…(…) 2 x DILM7-…(…) The motor-starter combinations consist of the motor protective circuit breaker
or a circuit breaker and a contactor. They conform with IEC/EN 60947-4-1 or
VDE 0660 Part 102.
Iq = conditional rated current
PKZM0-0,4 DILM7-…(…) DILM7-…(…)
PKZM0-0,63 DILM7-…(…) DILM7-…(…)
PKZM0-0,63 DILM7-…(…) DILM7-…(…)
PKZM0-1 DILM7-…(…) DILM7-…(…)
PKZM0-1,6 DILM7-…(…) DILM7-…(…)
PKZM0-1,6 DILM7-…(…) DILM7-…(…)
PKZM0-2,5 DILM7-…(…) DILM7-…(…)
PKZM0-4 DILM7-…(…) DILM7-…(…)
PKZM0-4 DILM7-…(…) DILM7-…(…)
PKZM0-6,3 DILM7-…(…) DILM7-…(…)
PKZM0-10 DILM9-…(…) DILM17-…(…)
PKZM0-10 DILM9-…(…) DILM17-…(…)
PKZM0-12 DILM12-…(…) DILM17-…(…)
PKZM0-16 DILM17-…(…) DILM17-…(…)
PKZM0-25 DILM25-…(…) DILM25-…(…)
PKZM0-32 DILM32-…(…) DILM32-…(…)
PKZM4-16 2 x DILM17-…(…) 2 x DILM17-…(…) The motor-starter combinations consist of the motor protective circuit breaker
or a circuit breaker and a contactor.
They conform with IEC/EN 60947-4-1 or VDE 0660 Part 102.
Iq = rated conditional short-circuit current.
PKZM4-16 DILM17-…(…) DILM17-…(…)
PKZM4-25 DILM25-…(…) DILM25-…(…)
PKZM4-32 DILM32-…(…) DILM32-…(…)
PKZM4-40 DILM40(…) DILM40(…)
PKZM4-50 DILM50(…) DILM50(…)
PKZM4-58 DILM65(…) DILM65(…)
PKZM4-63 DILM65(…) DILM65(…)
Further information Page
Technical data PKZM0 ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
Other operating voltages ￫5/73
DILM accessories ￫5/54
Further information Page
Technical data PKZM0 ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
Other operating voltages ￫5/74
DILM accessories ￫5/54
