Motor-starter combinations
DOL starters
Starters on busbar adapter
Motor starters
actuating voltage
24 V DC
Price
See price
list
Std.
pack
Motor
protective
circuit
breaker
Contactor DOL starter
wiring set
Busbar
adapter
Notes
Part no.
Article no.
Mechanical con-
nection module
and electrical
contact module
Type Type Type Type
MSC-D-0.25-M7(24VDC)/BBA1)
102964
1 off PKZM0-0,25 DILM7-10(…) PKZM0-XDM12 BBA0-25 The DOL starters (complete devices) consist of a
motor protective circuit breaker PKZM0 and a
contactor DILM. These combinations are
mounted on busbars.
The connection of the main circuit between PKZ
and contactor is established with electrical
contact modules.
Cannot be combined with standard auxiliary
contact NHI-E-...-PKZ0-C with spring-loaded
terminal.
1) To assemble Type F starters that conform
with UL508, incoming terminals BK25/3-PKZ0-E
and, if necessary, three-phase terminal blocks
B3.../...-PKZ0 can be added to motor starter
combinations.
Type F starter ￫Page 8/34
MSC-D-0.4-M7(24VDC)/BBA1)
102965
PKZM0-0,4 DILM7-10(…) PKZM0-XDM12
MSC-D-0.63-M7(24VDC)/BBA1)
102966
PKZM0-0,63 DILM7-10(…) PKZM0-XDM12
MSC-D-1-M7(24VDC)/BBA1)
102967
PKZM0-1 DILM7-10(…) PKZM0-XDM12
MSC-D-1.6-M7(24VDC)/BBA1)
102968
PKZM0-1,6 DILM7-10(…) PKZM0-XDM12
MSC-D-2.5-M7(24VDC)/BBA1)
102969
PKZM0-2,5 DILM7-10(…) PKZM0-XDM12
MSC-D-4-M7(24VDC)/BBA1)
102970
PKZM0-4 DILM7-10(…) PKZM0-XDM12
MSC-D-6.3-M7(24VDC)/BBA
102971
PKZM0-6,3 DILM7-10(…) PKZM0-XDM12
MSC-D-10-M7(24VDC)/BBA
102972
PKZM0-10 DILM7-10(…) PKZM0-XDM12
MSC-D-10-M9(24VDC)/BBA
102973
PKZM0-10 DILM9-10(…) PKZM0-XDM12
MSC-D-12-M12(24VDC)/BBA
102974
PKZM0-12 DILM12-10(…) PKZM0-XDM12
MSC-D-16-M15(24VDC)/BBA
102975
PKZM0-16 DILM15-10(…) PKZM0-XDM12
MSC-D-10-M17(24VDC)/BBA
102976
PKZM0-10 DILM17-10(…) PKZM0-XM32DE BBA0-32
MSC-D-12-M17(24VDC)/BBA
102977
PKZM0-12 DILM17-10(…) PKZM0-XM32DE
MSC-D-16-M17(24VDC)/BBA
102978
PKZM0-16 DILM17-10(…) PKZM0-XM32DE
MSC-D-25-M25(24VDC)/BBA
102979
PKZM0-25 DILM25-10(…) PKZM0-XM32DE
MSC-D-32-M32(24VDC)/BBA
102980
PKZM0-32 DILM32-10(…) PKZM0-XM32DE
Further information Page
Technical data PKZM0 ￫Chapter 7
Accessories PKZ ￫7/10
Technical data DILM ￫Chapter 5
DILM accessories ￫5/54
