Adaptaflex Product Catalogue |
LIT211GB 0715
3
Metallic conduit systems
Type SPL & LFH-SPL - Adaptasteel
Type SPL - Adaptasteel
Liquid Tight Oil Resistant Covered Steel Flexible Conduit
Materials:
PVC Covered Galvanised Steel /
Colour:
Black (BL), Grey (GR), Orange (OR)
Nominal
Outside
US
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Conduit Size Diameter
Radius
Length
SPL10
10mm
11.8mm
1/4”
7.0mm
40mm
10, 25, 50m
SPL12
12mm
14.2mm
5/16”
10.0mm
45mm
10, 25, 50m
SPL16
16mm
17.8mm
3/8”
12.5mm
50mm
10, 25, 50m
SPL20
20mm
21.1mm
1/2”
15.9mm
80mm
10, 25, 50m
SPL25
25mm
26.4mm
3/4”
21.0mm
110mm
10, 25, 50m
SPL32
32mm
33.1mm
1”
26.7mm
145mm
10, 25m
SPL40
40mm
41.8mm
1 1/4”
35.4mm
180mm
10, 25m
SPL50
50mm
47.9mm
1 1/2”
40.4mm
240mm
10, 25m
SPL63
63mm
59.7mm
2”
51.6mm
345mm
10, 25m
To order quote part number, colour & reel length, e.g. SPL12/BL/50M
Temperature Range
Static Applications: -20ºC to +105ºC
Moving Applications: -5ºC to +105ºC
Flexibility & Fatigue Life
Medium Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
Very High
Approvals
Type SPL
Liquid Tight Oil Resistant
Covered Steel Flexible Conduit
IP Rating
Appropriate Fitting
For use with:
Type SPL
IP40
N/A
IP65
N/A
IP66
Type SPL - Type M, C45 & C90
IP67
Type SPL - Type A, B, M, C45 & C90
IP68
Type SPL - Type M, C45 & C90 (10 bar 30 mins)
IP69K
Type SPL - Type M, C45 & C90
Type LFH-SPL - Adaptasteel
Low Fire Hazard Performance Covered Steel Flexible Conduit
Materials:
Low Fire Hazard Jacket Covered Galvanised Steel /
Colour:
Black (BL) Only
Nominal
Outside
US
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Conduit Size Diameter
Radius
Length
LFH-SPL16
16mm
17.0mm
3/8”
13.0mm
35mm
10, 25m
LFH-SPL20
20mm
21.5mm
1/2”
16.9mm
45mm
10, 25m
LFH-SPL25
25mm
26.0mm
3/4”
21.4mm
55mm
10, 25m
LFH-SPL32
32mm
34.0mm
1”
28.1mm
60mm
10, 25m
LFH-SPL40
40mm
44.5mm
1 1/4”
37.7mm
80mm
10m
LFH-SPL50
50mm
55.0mm
1 1/2”
48.4mm
90mm
10m
LFH-SPL63
63mm
64.5mm
2”
57.5mm
115mm
10m
To order quote part number, colour & reel length, e.g. LFH-SPL16/BL/25M
Temperature Range
Static Applications: -20ºC to +90ºC
Moving Applications: -5ºC to +105ºC
Flexibility & Fatigue Life
Medium Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
High
Approvals
Type LFH-SPL
Low Fire Hazard Performance
Covered Steel Flexible Conduit
IP Rating
Appropriate Fitting
For use with:
Type SPL
IP40
N/A
IP65
N/A
IP66
Type SPL - Type M, C45 & C90
IP67
Type SPL - Type A, B, M, C45 & C90
IP68
Type SPL - Type M, C45 & C90 (10 bar 30 mins)
IP69K
Type SPL - Type M, C45 & C90
EN45545-2 HL3 - R22 & R23
