The
NEW
SPL-EF conduit systems are Enhanced Fire
Performance rated, highly flexible, liquid tight with
a wide temperature operating range.
Designed to meet the demand for ‘interoperability’ and
compliance with stringent local and European fire safety
requirements in the rail infrastructure market, the
SPL-EF system, is accredited with the EN45545-2 standard
achieving the highest HL3 fire performance rating for both
interior and exterior locations.
The system provides higher performance levels of flexibility,
impact and abrasion resistance, combined with enhanced
chemical resistances especially to oils and greases, with a
much higher and lower temperature rating (-40°C to +105°C),
than any other metallic conduit system with a EN45545-2
HL3 rating.
Advantages include:
– EN45545-2 and BS EN 61386-1 & 23 accreditation
– HL3 - R22 & R23 rating
– Up to IP69K rating
– High flexibility
– Oil and hydrocarbons resistant
– Suitable for wide use underground and in any part of
train vehicles and infrastructure
Metallic conduit systems
Type SPL-EF - Adaptasteel
Type SPL-EF - Adaptasteel
NEW
Enhanced Fire Performance Covered Steel Flexible Conduit
Materials:
Thermoplastic Jacket Covered Galvanised Steel /
Colour:
Black (BL) Only
Nominal
Outside
US
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Conduit Size Diameter
Radius
Length
SPL-EF12
12mm
14.2mm
5/16”
12.0mm
45mm
10, 25, 50m
SPL-EF16
16mm
17.8mm
3/8”
12.5mm
50mm
10, 25, 50m
SPL-EF20
20mm
21.1mm
1/2”
15.9mm
80mm
10, 25, 50m
SPL-EF25
25mm
26.4mm
3/4”
21.0mm
110mm
10, 25, 50m
SPL-EF32
32mm
33.1mm
1”
26.7mm
145mm
10, 25, 50m
SPL-EF40
40mm
41.8mm
1 1/4”
35.4mm
180mm
10, 25m
SPL-EF50
50mm
47.9mm
1 1/2”
40.4mm
240mm
10, 25m
To order quote part number, colour & reel length, e.g. SPL-EF12/BL/50M
Temperature Range
Static Applications: -40ºC to +105ºC
Moving Applications: -30ºC to +105ºC
Flexibility & Fatigue Life
Very High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
Type SPL-EF
Enhanced Fire Performance
Covered Steel Flexible Conduit
IP Rating
Appropriate Fitting
For use with:
Type SPL
IP40
N/A
IP65
N/A
IP66
Type SPL - Type M, C45 & C90
IP67
Type SPL - Type A, B, M, C45 & C90
IP68
Type SPL - Type M, C45 & C90 (10 bar 30 mins)
IP69K
Type SPL - Type M, C45 & C90
EN45545-2 HL3 - R22 & R23
