89 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
3/13
3
Metallic conduit systems
Type C & E - Adaptasteel
Type C
Smooth Entry Bush
Type E - Adaptasteel
Conduit Terminator
/
Cable Protection at exit point
Materials:
Nickel plated brass
Nominal
Part No.
Conduit Size
SP12/E
12mm
SP16/E
16mm
SP20/E
20mm
SP25/E
25mm
SP32/E
32mm
SP40/E
40mm
SP50/E
50mm
Type E
Conduit Terminator
Type C - Adaptasteel
Smooth Entry Bush
/
For locking conduit into plain holes in enclosures
Materials:
Nickel plated brass
Nominal
Hole
Part No.
Conduit Size Size
SP10/9/C
10mm
9mm
SP12/12/C 12mm
12mm
SP16/16/C 16mm
16mm
SP20/20/C 20mm
20mm
SP25/25/C 25mm
25mm
SP32/32/C 32mm
32mm
SP40/40/C 40mm
40mm
SP50/51/C 50mm
51mm
SP63/61/C 63mm
61mm
SP75/75/C 75mm
75mm
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
IP Rating
Appropriate Conduit
For use with:
Type SP / SN / LFH-SP
IP54
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
IP Rating
Appropriate Conduit
For use with:
Type SP / SN / LFH-SP
IP54
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
