Metallic conduit systems
Type SPUL & A - Adaptasteel
Type SPUL - Adaptasteel
Liquid Tight UL Listed & CSA Approved Covered Steel Flexible Conduit
Materials:
PVC Covered Galvanised Steel with Copper Packing /
Colour:
Black (BL), Grey (GR)
Nominal
Outside
US
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Conduit Size Diameter
Radius
Length
SPUL16
16mm
17.8mm
3/8”
12.5mm
50mm
25, 50m
SPUL20
20mm
21.1mm
1/2”
15.9mm
80mm
50m
SPUL25
25mm
26.4mm
3/4”
21.0mm
110mm
25, 50m
SPUL32
32mm
33.1mm
1”
26.7mm
145mm
25m
SPUL40
40mm
41.8mm
1 1/4”
35.4mm
180mm
25m
SPUL50
50mm
47.9mm
1 1/2”
40.4mm
240mm
25m
SPUL63
63mm
59.7mm
2”
51.6mm
345mm
10, 25m
To order quote part number, colour & reel length, e.g. SPUL16/BL/25M
Temperature Range
Static Applications: -20ºC to +75ºC
Moving Applications: -5ºC to +105ºC
Flexibility & Fatigue Life
Medium Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
High
Approvals
Type SPUL
Covered Steel Flexible Conduit
IP Rating
Appropriate Fitting
For use with:
Type SPL
IP40
N/A
IP65
N/A
IP66
Type SPL - Type M, C45 & C90
IP67
Type SPL - Type A, B, & M, C45 & C90
IP68
Type SPL - Type M, C45 & C90 (10 bar 30 mins)
IP69K
Type SPL - Type M, C45 & C90
Type A
Straight Fitting
Type A - Adaptasteel
Straight Fitting - Fixed External Male Thread
/
For insertion into threaded entries & knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
US
Metric
Part No.
Conduit Size Conduit Size Thread
SPL16/M16/A
16mm
3/8”
M16
SPL16/M20/A
16mm
3/8”
M20
SPL20/M20/A
20mm
1/2”
M20
SPL25/M25/A
25mm
3/4”
M25
SPL32/M32/A 32mm
1”
M32
Temperature Range
Static Applications: -65ºC to +150ºC
Moving Applications: -45ºC to +150ºC
Approvals
IP Rating
Appropriate Conduit
For use with:
Type SPL / SPLHC / SPUL / SPL-EF / LFH-SPL
IP40
N/A
IP65
N/A
IP66
N/A
IP67
Yes
IP68
N/A
IP69K
N/A
UL514B
File No. E76358
