98 / 156
3/22
Adaptaflex Product Catalogue |
LIT211GB 0715
3
Metallic conduit systems
EMI screen Type SSB & SSBGS - Adaptasteel
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Type SB
IP40
Type SB - Type A & B
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Type SSB - Adaptasteel
Overbraided, Standard EMI Screening, Flexible Conduit
Materials:
Stainless Steel Conduit, Stainless Steel Overbraid
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
SSB12
12mm
14.0mm
10.3mm
30mm
25m
SSB16
16mm
17.5mm
13.0mm
35mm
25m
SSB20
20mm
21.5mm
16.9mm
45mm
25m
SSB25
25mm
26.0mm
21.4mm
55mm
25m
SSB32
32mm
34.0mm
28.1mm
60mm
10m
To order quote part number & reel length, e.g. SSB12/25M
Type SSB
Overbraided,
Standard EMI Screening,
Flexible Conduit
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Type SB
IP40
Type SB - Type A & B
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Type SSBGS - Adaptasteel
Overbraided, Standard EMI Screening, Flexible Conduit
Materials:
Galvanised Steel Conduit, Stainless Steel Overbraid
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
SSBGS12
12mm
14.0mm
10.3mm
30mm
25m
SSBGS16
16mm
17.5mm
13.0mm
35mm
25m
SSBGS20
20mm
21.5mm
16.9mm
45mm
25m
SSBGS25
25mm
26.0mm
21.4mm
55mm
25m
SSBGS32
32mm
34.0mm
28.1mm
60mm
10m
To order quote part number & reel length, e.g. SSBGS12/25M
Type SSBGS
Overbraided,
Standard EMI Screening,
Flexible Conduit
