101 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
3/25
3
Metallic conduit systems
EMI screen, liquid resistant Type A & B - Adaptasteel
IP Rating
Appropriate Conduit
For use with:
Type SPB / SPTC
IP54
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
Type A
Straight Fitting
Type A - Adaptasteel
Straight Fitting - Fixed External Male Thread
/
For insertion into knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
Metric
Part No.
Conduit Size Thread
SPB10/M12/A 10mm
M12
SPB12/M16/A 12mm
M16
SPB16/M16/A 16mm
M16
SPB20/M20/A 20mm
M20
SPB25/M25/A 25mm
M25
SPB32/M32/A 32mm
M32
SPB40/M40/A 40mm
M40
SPB50/M50/A 50mm
M50
Type B
Straight Fitting
Type B - Adaptasteel
Straight Fitting - Swivel External Male Thread
/
For insertion into threaded entries & knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
Metric
Part No.
Conduit Size Thread
SPB10/M12/B 10mm
M12
SPB12/M16/B 12mm
M16
SPB16/M16/B 16mm
M16
SPB20/M20/B 20mm
M20
SPB25/M25/B 25mm
M25
SPB32/M32/B 32mm
M32
SPB40/M40/B 40mm
M40
SPB50/M50/B 50mm
M50
IP Rating
Appropriate Conduit
For use with:
Type SPB / SPTC
IP54
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Fitting Characteristics
Approvals
