Adaptaflex Product Catalogue |
LIT211GB 0715
3
Metallic conduit systems
EMI screen, liquid resistant Type SPB & SPTC - Adaptasteel
Temperature Range
Static Applications: -15ºC to +70ºC
Moving Applications: -5ºC to +90ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Type SPB
IP54
Type SB - Type A & B
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Type SPB - Adaptasteel
Overbraided, Enhanced EMI Screening, Flexible Conduit
Materials:
Galvanised Steel Conduit with PVC Covering, Galvanised Steel Overbraid
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
SPB10
10mm
11.5mm
6.8mm
25mm
25m
SPB12
12mm
15.5mm
10.3mm
25mm
25m
SPB16
16mm
18.5mm
13.0mm
30mm
25m
SPB20
20mm
23.0mm
16.9mm
35mm
25m
SPB25
25mm
27.5mm
21.4mm
55mm
25m
SPB32
32mm
35.5mm
28.1mm
60mm
10m
SPB40
40mm
45.1mm
37.7mm
80mm
10m
SPB50
50mm
57.5mm
48.4mm
90mm
10m
To order quote part number & reel length, e.g. SPB12/25M
Type SPB
Overbraided,
Enhanced EMI Screening,
Flexible Conduit
Temperature Range
Static Applications: -15ºC to +70ºC
Moving Applications: -5ºC to +90ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Type SB
IP54
Type SB - Type A & B
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Type SPTC - Adaptasteel
Overbraided Tinned Copper, High EMI Screening, Flexible Conduit
Materials:
Galvanised Steel Conduit with PVC Covering, Tinned Copper Overbraid
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
SPTC10
10mm
11.5mm
6.8mm
25mm
25m
SPTC12
12mm
15.5mm
10.3mm
25mm
25m
SPTC16
16mm
18.5mm
13.0mm
30mm
25m
SPTC20
20mm
23.0mm
16.9mm
35mm
25m
SPTC25
25mm
27.5mm
21.4mm
55mm
25m
SPTC32
32mm
35.5mm
28.1mm
60mm
10m
SPTC40
40mm
45.1mm
37.7mm
80mm
10m
SPTC50
50mm
57.5mm
48.4mm
90mm
10m
To order quote part number & reel length, e.g. SPTC12/25M
Type SPTC
Overbraided Tinned Copper,
High EMI Screening,
Flexible Conduit
