96 / 156
3/20
Adaptaflex Product Catalogue |
LIT211GB 0715
3
Metallic conduit systems
Type C90 & 45 - Adaptasteel
Type A
90º Combined
Fitting & Elbow
Type C90 - Adaptasteel
90º Combined Fitting & Elbow - Swivel External Male Thread
/
For insertion into threaded entries & knockouts using a locknut
(order locknut separately)
Materials:
Nickel plated brass
Nominal
US
Metric
Nominal
US
NPT
Part No.
Conduit Size Conduit Size Thread
Part No.
Conduit Size Conduit Size Thread
SPL16/M16/C90 16mm
3/8”
M16
SPL16/038/C90
16mm
3/8”
3/8”
SPL16/M20/C90 16mm
3/8”
M20
SPL16/050/C90
16mm
3/8”
3/8”
SPL20/M20/C90 20mm
1/2”
M20
SPL20/050/C90
20mm
1/2”
1/2”
SPL25/M25/C90 25mm
3/4”
M25
SPL25/075/C90
25mm
3/4”
3/4”
SPL32/M32/C90 32mm
1”
M32
SPL32/100/C90
32mm
1”
1”
SPL40/M40/C90 40mm
1 1/4”
M40
SPL40/125/C90
40mm
1 1/4”
1 1/4”
SPL50/M50/C90 50mm
1 1/2”
M50
SPL50/150/C90
50mm
1 1/2”
1 1/2”
SPL63/M63/C90 63mm
2”
M63
SPL63/200/C90
63mm
2”
2”
Temperature Range
Static Applications: -65ºC to +150ºC
Moving Applications: -45ºC to +150ºC
Approvals
IP Rating
Appropriate Conduit
For use with:
Type SPL / SPLHC / SPUL / SPL-EF / LFH-SPL
IP54
N/A
IP65
N/A
IP66
Yes
IP67
Yes
IP68
Yes (10 bar 30 mins)
IP69K
Yes
Type 45 - Adaptasteel
45º Elbow - Fixed External Male Thread
/
For insertion into threaded entries & knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
US
Metric
Nominal
US
NPT
Part No.
Conduit Size Conduit Size Thread
Part No.
Conduit Size Conduit Size Thread
SPL16/M16/C45 16mm
3/8”
M16
SPL16/038/C45
16mm
3/8”
3/8”
SPL16/M20/C45 16mm
3/8”
M20
SPL16/050/C45
16mm
3/8”
3/8”
SPL20/M20/C45 20mm
1/2”
M20
SPL20/050/C45
20mm
1/2”
1/2”
SPL25/M25/C45 25mm
3/4”
M25
SPL25/075/C45
25mm
3/4”
3/4”
SPL32/M32/C45 32mm
1”
M32
SPL32/100/C45
32mm
1”
1”
SPL40/M40/C45 40mm
1 1/4”
M40
SPL40/125/C45
40mm
1 1/4”
1 1/4”
SPL50/M50/C45 50mm
1 1/2”
M50
SPL50/150/C45
50mm
1 1/2”
1 1/2”
SPL63/M63/C45 63mm
2”
M63
SPL63/200/C45
63mm
2”
2”
Temperature Range
Static Applications: -65ºC to +150ºC
Moving Applications: -45ºC to +150ºC
Approvals
IP Rating
Appropriate Conduit
For use with:
Type SPL / SPLHC / SPUL / SPL-EF / LFH-SPL
IP54
N/A
IP65
N/A
IP66
Yes
IP67
Yes
IP68
Yes (10 bar 30 mins)
IP69K
Yes
UL514B
File No. E60625
UL514B
File No. E60625
Type 45
45º Elbow
