Adaptaflex Product Catalogue |
LIT211GB 0715
3
Metallic conduit systems
Type F & C - Adaptasteel
IP Rating
Appropriate Conduit
For use with:
Type S / SS
IP40
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
Type F
Straight Fitting
Type F - Adaptasteel
Straight Fitting - Fixed Internal Female Thread
/
For attaching to external threads & other fittings
Materials:
Nickel plated brass
Nominal
Metric
Part No.
Conduit Size Thread
S20/M20/F 20mm
M20
S25/M25/F 25mm
M25
S32/M32/F 32mm
M32
IP Rating
Appropriate Conduit
For use with:
Type S / SS
IP40
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
Type C
Smooth Entry Bush
Type C - Adaptasteel
Smooth Entry Bush
/
For locking conduit into plain holes in enclosures
Materials:
Nickel plated brass
Nominal
Part No.
Conduit Size Hole Size
S10/9/C
10mm
9mm
S12/12/C 12mm
12mm
S16/16/C 16mm
16mm
S20/20/C 20mm
20mm
S25/25/C 25mm
25mm
S32/32/C 32mm
32mm
S40/40/C 40mm
40mm
S50/51/C 50mm
51mm
S63/61/C 63mm
61mm
S75/75/C 75mm
75mm
