83 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
3/7
3
Metallic conduit systems
Type A & B - Adaptasteel
IP Rating
Appropriate Conduit
For use with:
Type S / SS
IP40
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Approvals
Type A
Straight Fitting
Type A - Adaptasteel
Straight Fitting - Fixed External Male Thread
/
For insertion into knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
Metric
Nominal
PG
Part No.
Conduit Size Thread
Part No.
Conduit Size Thread
S10/M12/A
10mm
M12
S10/PG7/A
10mm
PG7
S12/M16/A
12mm
M16
S12/PG9/A
12mm
PG9
S16/M16/A
16mm
M16
S16/PG11/A
16mm
PG11
S16/M20/A
16mm
M20
S20/M20/A 20mm
M20
S20/PG16/A
20mm
PG16
S25/M25/A 25mm
M25
S25/PG21/A
25mm
PG21
S32/M32/A 32mm
M32
S32/PG29/A
32mm
PG29
S40/M40/A 40mm
M40
S40/PG36/A
40mm
PG36
S50/M50/A 50mm
M50
S50/PG42/A
50mm
PG42
S63/M63/A 63mm
M63
S63/PG48/A
63mm
PG48
S75/M75/A
75mm
M75
IP Rating
Appropriate Conduit
For use with:
Type S / SS
IP40
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Fitting Characteristics
Approvals
Type B
Straight Fitting
Type B - Adaptasteel
Straight Fitting - Swivel External Male Thread
/
For insertion into threaded entries & knockouts using a locknut (order locknut separately)
Materials:
Nickel plated brass
Nominal
Metric
Nominal
PG
Part No.
Conduit Size Thread
Part No.
Conduit Size Thread
S10/M12/B
10mm
M12
S10/PG7/B
10mm
PG7
S12/M16/B
12mm
M16
S12/PG9/B
12mm
PG9
S16/M20/B 16mm
M16
S16/PG11/B
16mm
PG11
S16/M20/B 16mm
M20
S20/M20/B 20mm
M20
S20/PG16/B
20mm
PG16
S25/M25/B 25mm
M25
S25/PG21/B
25mm
PG21
S32/M32/B 32mm
M32
S32/PG29/B
32mm
PG29
S40/M40/B 40mm
M40
S40/PG36/B
40mm
PG36
S50/M50/B 50mm
M50
S50/PG42/B
50mm
PG42
