82 / 156
3/6
Adaptaflex Product Catalogue |
LIT211GB 0715
3
IP Rating
Appropriate Fitting
For use with:
Type S
IP40
Type S - Type A, B, F & C
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Metallic conduit systems
Type S & SS - Adaptasteel
Type S - Adaptasteel
Inherent Low Fire Hazard Steel Conduit
/
Materials:
Galvanised Steel - General Purpose
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
S10
10mm
9.1mm
7.0mm
25mm
25, 50m
S12
12mm
13.0mm
10.3mm
30mm
10, 25, 50m
S16
16mm
16.0mm
13.0mm
35mm
10, 25, 50m
S20
20mm
20.5mm
16.9mm
45mm
10, 25, 50m
S25
25mm
25.0mm
21.4mm
55mm
10, 25, 50m
S32
32mm
32.0mm
28.1mm
60mm
10, 25m
S40
40mm
42.5mm
37.7mm
80mm
10, 25m
S50
50mm
53.0mm
48.4mm
90mm
10, 25m
S63
63mm
62.5mm
57.5mm
115mm
10m
S75
75mm
77.0mm
70.0mm
150mm
10m
To order quote part no, & reel length, e.g. S12/25M
Temperature Range
Static Applications: -50ºC to +300ºC
Moving Applications: -45ºC to +250ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
UV Resistance
Very High
Approvals
Type S
Inherent Low Fire Hazard
Steel Conduit
Type SS - Adaptasteel
Inherent Low Fire Hazard Steel Conduit
/
Materials:
Stainless Steel 316 - Corrosion Resistant
Nominal
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Diameter
Diameter
Radius
Length
SS10
10mm
9.0mm
6.8mm
25mm
25, 50m
SS12
12mm
13.0mm
10.3mm
30mm
25, 50m
SS16
16mm
16.0mm
13mm
35mm
10, 25, 50m
SS20
20mm
20.5mm
16.9mm
45mm
10, 25, 50m
SS25
25mm
25.0mm
21.4mm
55mm
10, 25, 50m
SS32
32mm
32.0mm
28.1mm
60mm
10, 25m
To order quote part no, & reel length, e.g. SS12/25M
Approvals
Type SS
Inherent Low Fire Hazard
Stainless Steel Conduit
Temperature Range
Static Applications: -50ºC to +350ºC
Moving Applications: -45ºC to +250ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
UV Resistance
Very High
IP Rating
Appropriate Fitting
For use with:
Type S
IP40
Type S - Type A, B, F & C
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
