Non-metallic conduit systems
Type PADL
Type PADL
Standard Weight Conduit
/
Materials:
Modified Polyamide (Nylon) 6 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PADL16
16mm
13
Coarse
15.8mm
11.3mm
45mm
50m or 100ft
PADL21
21mm
17
Coarse
21.2mm
14.5mm
60mm
50m or 100ft
PADL28
28mm
23
Coarse
28.5mm
22.6mm
70mm
50m or 100ft
PADL34
34mm
29
Coarse
34.5mm
27.7mm
75mm
100ft
PADL42
42mm
36
Coarse
42.5mm
35.2mm
80mm
100ft
PADL54
54mm
48
Coarse
54.5mm
46.0mm
95mm
100ft
To order quote part number, colour & reel length, e.g. PADL16/BL/50M
Type PADL
Standard Weight Conduit
Approvals
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS
IP40
N/A
IP65
N/A
IP66
AL or ATS
IP67
AL + ALS Seal or ATS
IP68
AL + ALS Seal or ATS
IP69K
AL + ALS Seal or ATS
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -18ºC to +120ºC
Flexibility & Fatigue Life
Medium Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
