Adaptaflex Product Catalogue |
LIT211GB 0715
2
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / ALS
IP40
Adaptaring
IP65
N/A
IP66
ATS, Adaptalok
IP67
ATS, Adaptalok + ALS Seal
IP68
ATS, Adaptalok + ALS Seal
IP69K
ATS, Adaptalok + ALS Seal
Non-metallic conduit systems
Type PF
Type PF
Standard Weight Conduit
/
Materials:
Modified Polyamide 12 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PFFS10
10mm
8.5
Fine
10.0mm
6.2mm
20mm
50m
PFFS13
13mm
10
Fine
13.0mm
9.9mm
30mm
50m
PFFS16
16mm
13
Fine
15.8mm
11.7mm
35mm
50m
PFFS21
21mm
17
Fine
21.2mm
16.6mm
40mm
50m
PFCS28
28mm
23
Coarse
28.5mm
21.7mm
50mm
50m
PFCS34
34mm
29
Coarse
34.5mm
27.7mm
60mm
25m
PFCS42
42mm
36
Coarse
42.5mm
35.5mm
65mm
25m
PFCS54
54mm
48
Coarse
54.5mm
46.6mm
75mm
25m
To order quote part number, colour & reel length, e.g. PFFS13/BL/50M
Temperature Range
Static Applications: -50ºC to +110ºC
Moving Applications: -45ºC to +120ºC
Flexibility & Fatigue Life
Very High Flexibility - Very High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
Type PF
Standard Weight Conduit
Type PF
Heavyweight Conduit
/
Materials:
Modified Polyamide 12 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PFFH13
13mm
10
Fine
13.0mm
9.7mm
40mm
50m
PFFH16
16mm
13
Fine
15.8mm
11.5mm
45mm
50m
PFCH21
21mm
17
Coarse
21.2mm
15.3mm
50mm
50m
PFCH28
28mm
23
Coarse
28.5mm
21.5mm
60mm
50m
PFCH34
34mm
29
Coarse
34.5mm
27.5mm
70mm
25m
PFCH42
42mm
36
Coarse
42.5mm
35.5mm
75mm
25m
PFCH54
54mm
48
Coarse
54.5mm
46.4mm
85mm
25m
To order quote part number, colour & reel length, e.g. PFFH13/BL/50M
Approvals
Type PF
Heavyweight Conduit
Temperature Range
Static Applications: -50ºC to +110ºC
Moving Applications: -45ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / ALS
IP40
Adaptaring
IP65
N/A
IP66
ATS, Adaptalok
IP67
ATS, Adaptalok + ALS Seal
IP68
ATS, Adaptalok + ALS Seal
IP69K
ATS, Adaptalok + ALS Seal
EN45545-2 HL2 - R22 & R23
EN45542-2 HL2 - R22 & R23
