2
Non-metallic conduit systems
Type PI
Type PI
Standard Weight Conduit
/
Materials:
Modified Polyamide 11 /
Colour:
Black (BL), Grey (GR)
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel Length
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
(BL)
PIFS10
10mm
8.5
Fine
10.0mm
6.2mm
15mm
50m
PIFS13
13mm
10
Fine
13.0mm
9.9mm
25mm
50m
PIFS16
16mm
13
Fine
15.8mm
11.7mm
30mm
50m
PIFS21
21mm
17
Fine
21.2mm
16.6mm
35mm
50m
PICS28
28mm
23
Coarse
28.5mm
21.7mm
45mm
50m
PICS34
34mm
29
Coarse
34.5mm
27.7mm
55mm
25m
PICS42
42mm
36
Coarse
42.5mm
35.5mm
60mm
25m
PICS54
54mm
48
Coarse
54.5mm
46.6mm
70mm
25m
PICS80
80mm
70
Coarse
79.3mm
67.0mm
160mm
10m
PICS106
106mm
95
Coarse
106.0mm
91.0mm
210mm
10m
To order quote part number, colour & reel length, e.g. PIFS13/BL/50M
Type PI
Standard Weight Conduit
Type PI
Heavyweight Conduit
/
Materials:
Modified Polyamide 11 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PIFH13
13mm
10
Fine
13.0mm
9.7mm
30mm
50m
PIFH16
16mm
13
Fine
15.8mm
11.5mm
35mm
50m
PICH21
21mm
17
Coarse
21.2mm
15.3mm
40mm
50m
PICH28
28mm
23
Coarse
28.5mm
21.5mm
50mm
50m
PICH34
34mm
29
Coarse
34.5mm
27.5mm
60mm
25m
PICH42
42mm
36
Coarse
42.5mm
35.3mm
65mm
25m
PICH54
54mm
48
Coarse
54.5mm
46.4mm
75mm
25m
To order quote part number, colour & reel length, e.g. PIFH13/BL/50M
Approvals
Type PI
Heavyweight Conduit
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / Adaptaseal
IP40
Adaptaring
IP65
N/A
IP66
Adaptalok, ATS or Adaptaseal
IP67
Adaptalok + ALS Seal or ATS, Adaptaseal
IP68
Adaptalok + ALS Seal or ATS, Adaptaseal
IP69K
N/A
Temperature Range
Static Applications: -50ºC to +110ºC
Moving Applications: -45ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - Very High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / Adaptaseal / Jumbo
IP40
Adaptaring & Jumbo
IP65
Jumbo + SK Seal
IP66
Adaptalok, ATS or Adaptaseal
IP67
Adaptalok + ALS Seal or ATS, Adaptaseal
IP68
Adaptalok + ALS Seal or ATS, Adaptaseal
IP69K
Adaptalok + ALS Seal or ATS
Temperature Range
Static Applications: -50ºC to +110ºC
Moving Applications: -45ºC to +120ºC
Flexibility & Fatigue Life
Very High Flexibility - Very High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
