29 / 156
Adaptaflex Product Catalogue |
LIT211GB 0715
2/15
2
Non-metallic conduit systems
3-Way Coupler & Insert Seal - Adaptalok
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF / PK
IP66
N/A
IP67
Yes
IP68
Yes (1.1 bar 35mins)
IP69K
Yes (DIN 40050)
Insert Seal - Adaptalok
IP67/68/69k Insert Seal
/
Suitable for standard weight PA/PI/PR conduit (Black or Grey)
Materials:
Thermoplastic Elastomer /
Colour:
Yellow (Y) Only
Part No.
Conduit Pitch
ALS13/F
Fine
ALS16/F
Fine
ALS21/F
Fine
ALS28/C
Coarse
ALS34/C
Coarse
ALS42/C
Coarse
ALS54/C
Coarse
To order quote part number, e.g. ALS13/F
Note: Seal needs to be inserted into the appropriate conduit to upgrade fitting system
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Approvals
Insert Seal
IP67/68/69k Insert Seal
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF / PK
IP66
Yes
IP67
Yes + ALS Seal
IP68
Yes + ALS Seal
IP69K
Yes + ALS Seal
3-Way Coupler - Adaptalok
3-Way PA66 Fitting
/
For coupling three corrugated flexible conduits
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Nominal Conduit
Part No.
Size Combination
AL131010/Y 13x10x10mm
AL161313/Y 16x13x13mm
AL211616/Y 21x16x16mm
AL282121/Y 28x21x21mm
To order quote part number & body colour, e.g. AL131010/Y/BL
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Approvals
3-Way Coupler
3-Way PA66 Fitting
TYPE
APPROVED
