Non-metallic conduit systems
Type FL/45 & Swivel Coupler - Adaptalok
Type FL/45 - Adaptalok
45º Panel Mounting Swivel Flange
/
With integral face seal
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Part No.
Nominal Conduit Size
AL16/FL/45 16mm
AL21/FL/45 21mm
AL28/FL/45 28mm
AL54/FL/45 54mm
To order quote part number & body colour, e.g. AL16/FL/45/BL
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes + ALS Seal
IP68
Yes + ALS Seal
IP69K
Yes + ALS Seal
Swivel Coupler - Adaptalok
Straight PA66 Body Swivel Coupler
/
For coupling two corrugated flexible conduits
Materials:
Polyamide (Nylon) 66 + Aluminium /
Colour:
Black (BL) Only
Part No.
Nominal Conduit Size
AL13/A/U/BL 13mm
AL16/A/U/BL 16mm
AL21/A/U/BL 21mm
AL28/A/U/BL 28mm
AL34/A/U/BL 34mm
AL42/A/U/BL 42mm
AL54/A/U/BL 54mm
To order quote part number, e.g. AL13/A/U/BL
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Approvals
Swivel Coupler
Straight PA66 Body Swivel Coupler
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes + ALS Seal
IP68
Yes + ALS Seal
IP69K
Yes + ALS Seal
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Approvals
Type FL/45
45º Panel Mounting Swivel Flange
