Adaptaflex Product Catalogue |
LIT211GB 0715
2
Non-metallic conduit systems
Type FL/A, FL/C90 & FL/90 - Adaptalok
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes + ALS Seal
IP68
Yes + ALS Seal
IP69K
Yes + ALS Seal
Type FL/A - Adaptalok
Straight Panel Mounting Swivel Flange
/
With integral face seal
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Part No.
Nominal Conduit Size
AL16/FL/A 16mm
AL21/FL/A 21mm
AL28/FL/A 28mm
AL54/FL/A 54mm
To order quote part number & body colour, e.g. AL16/FL/A/BL
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Approvals
Type FL/A
Straight Panel Mounting
Swivel Flange
Type FL/C90 - Adaptalok
90º Elbow Body - Panel Mount Swivel Flange
/
For panel mounting via 2 hole fixing & integral face seal
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Part No.
Nominal Conduit Size
AL13/FL/C90 13mm
AL16/FL/C90 16mm
AL21/FL/C90 21mm
AL28/FL/C90 28mm
To order quote part number & body colour, e.g. AL13/FL/C90/BL
Type FL/C90
90º Elbow Body
Type FL/90 - Adaptalok
90º Elbow Fitting - Panel Mount Flange
/
For panel mounting via 4 hole fixing & integral face seal
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Part No.
Nominal Conduit Size
AL34/FL/C90 34mm
AL42/FL/C90 42mm
AL54/FL/C90 54mm
To order quote part number & body colour, e.g. AL34/FL/C90/BL
Type FL/90
90º Elbow Fitting
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes + ALS Seal
IP68
Yes + ALS Seal
IP69K
Yes + ALS Seal
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics (FLC/90 ONLY)
Approvals
