Adaptaflex Product Catalogue |
LIT211GB 0715
2
IP Rating
Appropriate Fitting
For use with:
Adaptalok / Adaptaseal
IP40
N/A
IP65
N/A
IP66
Adaptalok or Adaptaseal
IP67
Adaptalok + ALS Seal & Adaptaseal
IP68
Adaptalok + ALS Seal & Adaptaseal
IP69K
Adaptalok + ALS Seal
Non-metallic conduit systems
Type PR & CP
Type PR
Standard Weight Conduit
/
Materials:
Modified Polyamide (Nylon) 6 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PRFS13
13mm
10
Fine
13.0mm
9.4mm
35mm
50m
PRFS16
16mm
13
Fine
15.8mm
11.7mm
45mm
50m
PRFS21
21mm
17
Fine
21.2mm
16.6mm
60mm
50m
PRCS21
21mm
17
Coarse
21.2mm
14.7mm
60mm
50m
PRCS28
28mm
23
Coarse
28.5mm
21.7mm
70mm
50m
PRCS34
34mm
29
Coarse
34.5mm
27.7mm
75mm
50m
PRCS42
42mm
36
Coarse
42.5mm
35.1mm
90mm
25m
PRCS54
54mm
48
Coarse
54.5mm
46.6mm
95mm
25m
To order quote part number, colour & reel length, e.g. PRFS13/BL/50M
Type PR
Standard Weight Conduit
Type CP
Medium Weight Conduit
/
Materials:
Polyester /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
CPFM13
13mm
10
Fine
13.0mm
9.5mm
25mm
50m
CPFM16
16mm
13
Fine
15.8mm
11.3mm
30mm
50m
CPFM21
21mm
17
Fine
21.2mm
16.0mm
35mm
50m
CPCM28
28mm
23
Coarse
28.5mm
21.3mm
45mm
50m
CPCM34
34mm
29
Coarse
34.5mm
27.2mm
55mm
50m
CPCM42
42mm
36
Coarse
42.5mm
34.2mm
60mm
25m
CPCM54
54mm
48
Coarse
54.5mm
46.0mm
70mm
25m
To order quote part number, colour & reel length, e.g. CPFM13/BL/50M
Approvals
Type CP
Medium Weight Conduit
Temperature Range
Static Applications: -50ºC to +135ºC
Moving Applications: -25ºC to +150ºC
Flexibility & Fatigue Life
Very High Flexibility - Very High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / Adaptaseal
IP40
Adaptaring
IP65
N/A
IP66
Adaptalok or Adaptaseal
IP67
Adaptalok + ALS Seal or Adaptaseal
IP68
Adaptalok + ALS Seal or Adaptaseal
IP69K
Adaptalok + ALS Seal
EN45545-2 HL3 - R22 & R23
