Adaptaflex Product Catalogue |
LIT211GB 0715
2
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / Adaptaseal
IP40
N/A
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
Non-metallic conduit systems
Type PA
Type PA
Lightweight Conduit
/
Materials:
Polyamide (Nylon) 6 /
Colour:
Black (BL), Grey (GR)
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PAFL13
13mm
10
Fine
13.0mm
10.0mm
25mm
50m
PAFL16
16mm
13
Fine
15.8mm
11.9mm
35mm
50m
PAFL21
21mm
17
Fine
21.2mm
16.8mm
45mm
50m
PACL28
28mm
23
Coarse
28.5mm
22.2mm
50mm
50m
PACL34
34mm
29
Coarse
34.5mm
27.9mm
60mm
50m
PACL42
42mm
36
Coarse
42.5mm
35.2mm
65mm
25m
PACL54
54mm
48
Coarse
54.5mm
46.9mm
75mm
25m
To order quote part number, colour & reel length, e.g. PAFL13/BL/50M
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
Approvals
Type PA
Lightweight Conduit
Type PA-Slit
Lightweight Slit Conduit
/
Materials:
Polyamide (Nylon) 6 /
Colour:
Black (BL) Only
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PAFL13-S
13mm
10
Fine
13.0mm
10.0mm
25mm
50m
PAFL16-S
16mm
13
Fine
15.8mm
11.9mm
35mm
50m
PAFL21-S
21mm
17
Fine
21.2mm
16.8mm
45mm
50m
PACL28-S
28mm
23
Coarse
28.5mm
22.2mm
50mm
50m
PACL34-S
34mm
29
Coarse
34.5mm
27.9mm
60mm
50m
PACL42-S
42mm
36
Coarse
42.5mm
35.2mm
65mm
25m
PACL54-S
54mm
48
Coarse
54.5mm
46.9mm
75mm
25m
To order quote part number, colour & reel length, e.g. PAFL13-S/BL/50M
Approvals
Type PA
Lightweight Slit Conduit
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - High Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Halogen Free
UV Resistance
Very High
IP Rating
Appropriate Fitting
For use with:
Adaptalok / ATS / Adaptaring / Adaptaseal
IP40
Adaptaring
IP65
N/A
IP66
Adaptalok, ATS or Adaptaseal
IP67
Adaptalok + ALS Seal or ATS, Adaptaseal
IP68
Adaptalok + ALS Seal or ATS, Adaptaseal
IP69K
N/A
