References
ISP
Plus
weighing modules
Description
Composition
Reference
Weight
kg
ISP
Plus
weighing
modules
(1
weigher per module)
(1)
Supplied non
calibrated
Standard format module (sealable)
-
Load cell input 50 measurement/s
(
for 1 to 8 load cells)
- 2
discrete reflex outputs (for
threshold detection)
-
RS 485 output (for display unit)
TSX ISP Y101
0.420
-
TSX ISP Y101 module
-
TSX XBT N410 display unit (back-lit
LCD, preconfigured display)
-
Module/display unit connecting cable
(
length 3 m)
TSX ISP Y101
1.020
Intrinsically safe junction box
(2)
This box is inserted in the weighing system between the weight indicator and the junction box in
which the load cells are grouped. Its function is to limit any overvoltages and limit the current to
100
mA in the event of a short circuit.
The load cells and the metal junction box are the only devices in the explosive atmosphere. The
weight indicator is in a safe area.
Description
For use with
Marking Reference
Weight
kg
Zener barrier box
All types of load cells
and indicators
EEx ib II B
EEx ib II C
SM1 PY52
2.800
Remote indicator
Description
Length Reference
Weight
kg
Magelis display unit for ISP
Plus
weighing
module
24
V
c
external power supply
–
TSX XBT N410
0.380
Module/display unit connecting cables
10
m
SF3 CPY010
1.100
30
m
SF3 CPY030
3.400
Measurement cables
Description
For connection to Length Reference
Weight
kg
Measurement cables
6
conductors with
1
x 15-way SUB-D
connector for ISP
Plus
weighing module
Junction box for load
cells
3
m
SF3 PY32003
0.300
10
m
SF3 PY32010
1.100
20
m
SF3 PY32020
2.200
30
m
SF3 PY32030
3.400
40
m
SF3 PY32040
4.500
50
m
SF3 PY32050
5.600
80
m
SF3 PY32080
9.000
(1)
Setting up weighing modules requires Unity Pro
u
V2.0 or PL7 Junior/Pro
u
V4.1 software.
(2)
Equipment approved by the Laboratoire Central des Industries Electriques (LCIE) (Central
Laboratory for the Electrical Industries).
References
Presentation:
pages 4/48 ...
Description:
page 4/49
Functions:
page 4/50
SM1 PY52
SF3 PY32
ppp
TSX ISP Y101
TSX XBT N410
TSX ISP Y101
